Warranty Summary

TCL provides warranty cover against material or manufacturing faults, with RTB warranty covering parts and labor, excluding faulty installation.

Cooling Mode: Cools the room by circulating refrigerant and using a fan to blow cooled air. Set desired temperature and fan speed.

Heat Pump Mode: Heats the room by reversing the cooling cycle. Effective when outside temperature is not too low and indoor temperature is above 7°C. Set desired temperature and fan speed.

Fan Mode: Operates as a fan without cooling or heating. Fan speed can be adjusted. Temperature settings are disabled.

Dehumidify Mode: Removes moisture from the air. Fan speed is fixed at low, and temperature adjustment is disabled.

Auto Mode: Automatically selects cooling, heating, fan, or dehumidifying based on the difference between set and room temperatures. Temperature is not adjustable in this mode.

Timer Function: Set On or Off timers. Specify operation mode, temperature, and fan speed for On timer.

Sleep Mode: Adjusts temperature automatically for comfortable sleep and powers off after 10 hours.

Turbo Mode: Operates at maximum speed for 15 minutes for quick cooling or heating.

Swing: Controls vertical airflow direction. Horizontal direction is manually adjustable.

ECO Mode: Energy saving mode. Adjusts set temperature by 2°C in cooling (increase) or heating (decrease) mode.

IFeel Mode: Sets the unit temperature based on the remote control's location. Remote acts as a mobile thermostat.

Health Mode: Activates antibacterial ioniser function to improve air quality.

Troubleshooting and error codes

MALFUNCTION	POSSIBLE CAUSE
The appliance does not operate	Power failure Damaged indoor/outdoor unit fan motor Faulty compressor thermomagnetic circuit breaker Faulty protective device or fuses Loose connections Self protection in adverse conditions Voltage higher / lower than the voltage range Active TIMER-ON function Damaged electronic control board
Strange odour	Air filter dirty
Noise of running water	Back flow of liquid in the refrigerant circulation
A fine mist comes from the air outlet	This occurs when the air in the room becomes very cold, for example in the COOLING or DEHUMIDIFYING modes.
A strange noise can be heard	This noise is made by the expansion or contraction of the front panel due to variations in temperature and does not indicate a problem.
Insufficient airflow, either hot or cold	Inappropriate temperature setting. Air inlet or outlet of indoor or outdoor unit has been blocked. Air filter is blocked. Fan speed set at minimum. Other sources of heat in the room. No refrigerant.
The appliance does not respond to commands	Remote control is not near enough to indoor unit. Battery in Remote controller may have been exhausted. Obstacles between remote control and signal receiver in indoor unit.
The display is off	Active LED function Power failure
Switch off the air conditioner immediately and cut off the power supply in the event of:	Strange noises during operation. Faulty electronic control board Faulty fuses or switches. Spraying water or objects inside the appliance. Overheated cables. Very strong smells coming from the appliance.

Troubleshooting and error codes

MALFUNCTION	POSSIBLE CAUSE
The appliance does not operate	Power failure Damaged indoor/outdoor unit fan motor Faulty compressor thermomagnetic circuit breaker Faulty protective device or fuses Loose connections Self protection in adverse conditions Voltage higher / lower than the voltage range Active TIMER-ON function Damaged electronic control board
Strange odour	Air filter dirty
Noise of running water	Back flow of liquid in the refrigerant circulation
A fine mist comes from the air outlet	This occurs when the air in the room becomes very cold, for example in the COOLING or DEHUMIDIFYING modes.
A strange noise can be heard	This noise is made by the expansion or contraction of the front panel due to variations in temperature and does not indicate a problem.
Insufficient airflow, either hot or cold	Inappropriate temperature setting. Air inlet or outlet of indoor or outdoor unit has been blocked. Air filter is blocked. Fan speed set at minimum. Other sources of heat in the room. No refrigerant.
The appliance does not respond to commands	Remote control is not near enough to indoor unit. Battery in Remote controller may have been exhausted. Obstacles between remote control and signal receiver in indoor unit.
The display is off	Active LED function Power failure
Switch off the air conditioner immediately and cut off the power supply in the event of:	Strange noises during operation. Faulty electronic control board Faulty fuses or switches. Spraying water or objects inside the appliance. Overheated cables. Very strong smells coming from the appliance.
