Warranty Information

Refer to the separate warranty document for details.

To start using your Zanussi washing machine:

  1. Ensure the appliance is correctly installed and connected to power and water.
  2. Open the detergent drawer and add detergent and fabric conditioner as needed.
  3. Load the laundry into the drum, ensuring not to overload it.
  4. Close the door.
  5. Select a programme using the Programme selection touchpad (P).
  6. Adjust temperature and spin speed if necessary using the respective touchpads.
  7. Optionally, select additional options like Quick, Intensive, or Finish In.
  8. Press the Start/Pause touchpad (▷II) to begin the wash cycle.
  9. The display will show the programme duration or countdown.
  10. At the end of the programme, the appliance will stop automatically, and the door lock indicator will turn off, allowing you to open the door.
  11. Remove the laundry promptly.

Refer to specific sections for detailed instructions on options, care, cleaning, and troubleshooting.

Troubleshooting and error codes

Problem Possible solution
The programme does not start.
  • Make sure that the mains plug is connected to the mains socket.
  • Make sure that the appliance door is closed.
  • Make sure that there is not a damaged fuse in the fuse box.
  • Make sure that the Start/Pause has been pressed.
  • If the delay start is set, cancel the setting or wait for the end of countdown.
  • Deactivate the Child Lock function if it is on.
The appliance does not fill with water properly.
  • Make sure that the water tap is open.
  • Make sure that the pressure of the water supply is not too low. For this information, contact your local water authority.
  • Make sure that the water tap is not clogged.
  • Make sure that the filter of the inlet hose and the filter of the valve are not clogged. Refer to “Care and cleaning”.
  • Make sure that the inlet hose has no kinks or bends.
  • Make sure that the connection of the water inlet hose is correct.
The appliance does not drain the water.
  • Make sure that the sink spigot is not clogged.
  • Make sure that the drain hose has no kinks or bends.
  • Make sure that the connection of the drain hose is correct.
  • Set the drain option if you set a programme without drain phase.
  • Set the drain option if you set an option which ends with water in the drum.
  • If above mentioned solutions do not help, contact the Authorised Service Centre (as the filter of the drain pump may be clogged).
The spin phase does not operate or the washing cycle lasts longer than usually.
  • Adjust manually the items in the tub and start the spin phase again. This problem may be caused by balance problems.
  • Set the spin option.
  • Set the drain option if you set an option which ends with water in the drum.
  • If above mentioned solutions do not help, contact the Authorised Service Centre (as the filter of the drain pump may be clogged).
There is water on the floor.
  • Make sure that the couplings of the water hoses are tight and there is not water leakages.
  • Make sure that the water inlet hose and the drain hose have no damages.
  • Make sure you use the correct detergent and the correct quantity of it.
You cannot open the appliance door.
  • Make sure that the washing programme is finished.
  • Set the drain or the spin option if there is water in the drum.
  • Do the emergency drain procedure. See “Frost precautions” (in “Care and Cleaning” chapter).
The appliance makes an unusual noise.
  • Make sure the levelling of the appliance is correct. Refer to ‘Installation instruction’.
  • Make sure that the packaging and/or the transit bolts are removed. Refer to ‘Installation instruction’.
  • Add more laundry in the drum. The load may be too small.
The appliance fills with water and drain immediately.
  • Make sure that the drain hose is in the correct position. The end of the hose may be too low. Refer to ‘Installation instruction’.
The cycle is shorter than the time displayed.
  • The appliance calculates a new time according to the laundry load. See the ‘Consumption Values’ chapter.
The cycle is longer than the time displayed.
  • An unbalanced laundry load increases the duration time. This is a normal behaviour of the appliance.
The washing results are not satisfactory.
  • Increase the detergent quantity or use a different detergent.
  • Use special products to remove the stubborn stains before you wash the laundry.
  • Make sure that you set the correct temperature.
  • Decrease the laundry load.
You cannot set an option.
  • Make sure that you press only the wanted touch button(s).
