Refer to the warranty information provided separately with your appliance.
| Malfunction | Possible cause | Solution |
| Dryer does not work. | • Mains plug is not plugged in or fuse is not working correctly. • Loading door is open. • Have you pressed the START/PAUSE ▷II button? | • Plug in at mains socket. Check fuse in fuse box (domestic installation). • Close loading door. • Press the START/PAUSE ▷II button again. |
| Drying results unsatisfactory. | • Wrong programme selected. • Lint filter clogged. • Heat exchanger clogged with lint. • Incorrect volume of laundry. • Ventilation slots in base area covered up. • Residue on inside surface of drum or drum ribs. • Conductance of water at installation site differs from standard setting of machine. | • Select a different programme the next time you dry. • Clean lint filter. • Clean heat exchanger. • Observe recommended loading volumes. • Uncover ventilation slots in base area. • Clean inside surface of drum and drum ribs • Re-programme standard setting for degree of drying. |
| Loading door does not close. | • Fine strainer not in place and/or large mesh filter not locked in place. | • Install fine strainer and/or snap large mesh filter into place. |
| When pressing a button, the corresponding button flashes several times. | • Washing protection. After the start of the programme, the option can no longer be set. | • Turn the programme knob to “0” Set the programme again |
| Drying cycle ends shortly after programme starts. END → light illuminated. | • Not enough washing loaded or washing loaded is too dry for selected programme. | • Select time programme or higher drying level (e.g. EXTRA DRY instead of CUPBOARD ⌂). |
| Programme inactive, Water reservoir full light illuminated. | • Condensate tank is full. | • Empty condensate tank, then start programme with START/PAUSE ▷II button. |
| Drying cycle lasts an unusually long time. | • Lint filter clogged. • Heat exchanger clogged with lint. • DELICATE button pressed and load volume too big. • Load volume too big. • Laundry insufficiently predrained. | • Clean lint filter • Clean heat exchanger. • DELICATE is only suitable for use with loads of up to 3 kg! • Reduce load volume. • Laundry must be adequately pre-drained. |
