Manual for TCE 7124

Manual for TCE 7124

Brand: ZANUSSI

Category: Tumble Dryer

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:46 p.m.

Manual Publish Date: 2004-06-16

Warranty Information

This product comes with a 12-month warranty from the date of sale.

The control panel

  1. Programme guide: Select the correct drying programme.
  2. Mains-ON light: Indicates the appliance is switched on.
  3. ON/OFF button: Switches the dryer on and off.
  4. Low temperature button: For delicate items or time-controlled drying at lower temperature (1400W).
  5. Buzzer OFF button: Silences buzzer during anti-creasing phase.
  6. Start button: Starts the dryer or resumes after interruption.
  7. Programme phase indicator lights: Show 'Drying', 'Cooling', or 'End of programme' status.
  8. Programme/Time selector dial: Selects automatic or timed drying programmes.

Operating sequence

  1. Connect appliance.
  2. Open door, load laundry loosely.
  3. Close door.
  4. Press ON/OFF button.
  5. Select programme/time.
  6. Press low temperature and/or buzzer OFF buttons if needed.
  7. Press Start button for 2 seconds.
  8. Dryer operates with drum rotation and may include cooling and anti-creasing phases.
  9. Remove laundry at the end of the cycle.

After each use

  1. Turn selector dial to "0".
  2. Switch off using ON/OFF button.
  3. Clean filters.
  4. Empty water reservoir.

Troubleshooting and error codes

Problem Possible cause
The dryer does not work:

The door(s) is(are) open.

The plug is not fitted into the wall socket.

There is no electricity supply from the wall socket.

The selector dial is not set correctly.

The water reservoir is full or not correctly inserted (light is flashing).

The start button has not been depressed.
The dryer does not dry properly:

The filters are clogged.

The condenser is clogged.

The water reservoir is full.

The selected cycle is not suitable for the laundry.

Insufficient drying time.

The laundry has not been spun properly.

The low temperature function [symbol] has been selected.

Excessive laundry load.

The dryer is not correctly installed.
