Warranty Information
The manufacturer and dealer are not responsible for repair or failure within the guarantee period if used improperly.
Using the Control Panel:
1. Freezer setting: enables setting the freezer temperature.
2. Cooler setting: enables setting the cooler temperature.
3. Freezer set value screen.
4. Cooler set value screen.
5. Economy mode symbol.
6. Super freeze symbol.
7. Alarm symbol.
Operating your Fridge Freezer:
Initial settings: Freezer -18°C, Fridge +4°C.
Temperature Settings:
- Freezer: Press button to decrease temp; restarts from -16°C. Eco mode activates at -18°C.
- Cooler: Press button to decrease temp; restarts from +8°C.
Super Freeze Mode:
Purpose: Freeze large quantities of food quickly.
How to use: Press and hold freezer temp button for 3 seconds. Super freeze symbol lights up, machine beeps.
Note: Economy mode cannot be selected; Super Freeze mode can be cancelled the same way.
Recommended settings are provided for optimal performance.
1. Freezer setting: enables setting the freezer temperature.
2. Cooler setting: enables setting the cooler temperature.
3. Freezer set value screen.
4. Cooler set value screen.
5. Economy mode symbol.
6. Super freeze symbol.
7. Alarm symbol.
Operating your Fridge Freezer:
Initial settings: Freezer -18°C, Fridge +4°C.
Temperature Settings:
- Freezer: Press button to decrease temp; restarts from -16°C. Eco mode activates at -18°C.
- Cooler: Press button to decrease temp; restarts from +8°C.
Super Freeze Mode:
Purpose: Freeze large quantities of food quickly.
How to use: Press and hold freezer temp button for 3 seconds. Super freeze symbol lights up, machine beeps.
Note: Economy mode cannot be selected; Super Freeze mode can be cancelled the same way.
Recommended settings are provided for optimal performance.
Troubleshooting and error codes
| ERROR TYPE | MEANING | WHY | WHAT TO DO |
|---|---|---|---|
| E01 E02 E03 E06 E07 |
Sensor warning | Call Service for assistance as soon as possible. | |
| E08 | Low Voltage Warning | Power supply to the device has dropped to below 170 V. | - This is not a device failure, this error helps to prevent damages to the compressor. - The voltage needs to be increased back to required levels. If this warning continues an authorised technician needs to be contacted. |
| E09 | Freezer compartment is not cold enough | Likely to occur after long term power failure. | 1. Set the freezer temperature to a colder value or set Super Freeze. This should remove the error code once the required temperature has been reached. Keep doors closed to improve time taken to reach the correct temperature. 2. Remove any products which have thawed/defrosted during this error. They can be used within a short period of time. 3. Do not add any fresh produce to the freezer compartment until the correct temperature has been reached and the error is no longer. If this warning continues an authorised technician needs to be contacted. |
| E10 | Fridge compartment is not cold enough | Likely to occur after: - Long term power failure. - Hot food has been left in the fridge. |
1. Set the fridge temperature to a colder value or set Super Cool. This should remove the error code once the required temperature has been reached. Keep doors closed to improve time taken to reach the correct temperature. 2. Please empty the location at the front area of air duct channel holes and avoid putting food close to the sensor. If this warning continues an authorised technician needs to be contacted. |
| E11 | Fridge compartment is too cold | Various | 1. Check is Super Cool mode is activated 2. Reduce the fridge compartment temperature 3. Check to see if vents are clear and not clogged If this warning continues an authorised technician needs to be contacted. |
Your refrigerator does not operate
Check if:
• Your fridge is plugged in and switched on
• The fuse has blown
• Is the temperature adjustment right?
• The socket is faulty. To check this, plug another working appliance into the same socket.
Your refrigerator is performing poorly
Check if:
• Is the temperature adjustment right?
• Is the door of your fridge opened frequently and left open for a long while?
• The appliance is overloaded
• The doors are closed properly
• Did you put a dish or food on your fridge so that it contacts the rear wall of your fridge so as to prevent the air circulation?
• Is your fridge filled excessively?
• There is an adequate distance between the appliance and surrounding walls
• Is the ambient temperature within the range of values specified in the operating manual?
