Manual for TW-E5B
Uploaded: Nov. 21, 2025, 6:21 p.m.
Manual Publish Date: 2022-03-01
Charging and Powering
- Charging the earbuds: Place earbuds in the charging case. Indicator lights red while charging, turns off when complete (approx. 1.5 hours).
- Charging the charging case: Connect the USB power adapter. Charging takes approx. 2.5 hours.
- Turning on the power: Remove earbuds from the charging case. They turn on automatically.
- Turning off the power: Place earbuds back in the charging case.
- Remaining Battery Power: Check audio messages (High, Medium, Low) or indicators.
Bluetooth® Connectivity
- Pairing for the First Time: Remove earbuds, activate Bluetooth on your device, select "Yamaha...".
- Pairing with a Different Device: Hold function key (L) and + key (R) for 3 seconds to enter pairing standby.
- Connecting to a Device Already Paired: Activate Bluetooth on the device, remove earbuds from case. They connect automatically to the last paired device.
Wearing This Product
- Putting on the earbuds: Check L/R markings, insert into ears, and adjust for a snug fit.
- Replacing the eartips: Select the size that matches your ears and attach firmly.
Operation (Audio Playback and Phone Calls)
- Playing back Audio: Use function key for pause/play, + key for next track, - key for previous track. Volume controls: + for up, - for down.
- AMBIENT SOUND: Press function key twice to toggle ON/OFF.
- Talking on the phone: Press function key to receive/end calls. Hold for one second to ignore. Use +/ key for volume.
- Starting the voice assistant: Hold down the - (minus) key for about one second.
Troubleshooting and error codes
| Trouble | Solution |
|---|---|
| Earbuds (L) and (R) are not connecting properly. | Put the earbuds back into the charging case and then take them out again. The earbuds will turn on and both earbuds automatically connect. |
| The product is not pairing correctly. | If the information for this product still remains in the list of connected devices on your Bluetooth device, delete that information and try pairing again. "Pairing with a Different Device” (p.19) |
| The information for a Bluetooth device that was registered on this product was deleted. | If you pair a device beyond the maximum number of pairable Bluetooth devices, the information for device you first paired (the oldest pairing) is deleted. Pair this product once more. "Pairing with a Different Device” (p.19) |
| This product may already be connected to another Bluetooth device. | On your Bluetooth device, remove the connection with this product and then connect this product again. |
| This product and your Bluetooth device may be too far apart. | Move this product closer to the Bluetooth device. |
| A device that emits electromagnetic waves (such as a microwave oven, access point and so on) might be nearby. | Do not use this product near other devices that emit electromagnetic waves. |
