Manual for MAGICOK 20 L Elite-B (New) & 20 L Elite-S (New)

Manual for MAGICOK 20 L Elite-B (New) & 20 L Elite-S (New)

Brand: Whirlpool logo Whirlpool

Category: Microwave Ovens

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:06 p.m.

Warranty Information

None

Using the Microwave Oven

Setting the Clock:
  1. In standby mode, press CLOCK once or twice to select 24-hour or 12-hour cycle.
  2. Press TIME to set the hour.
  3. Press CLOCK to confirm.
  4. Press TIME to set the minute.
  5. Press CLOCK to confirm.
Microwave Cooking:
  1. Place food in the oven.
  2. Press MICRO to select power level (e.g., P100 for 100% power).
  3. Press TIME or +10 min to set cooking time (up to 95 minutes).
  4. Press START/+30sec to begin.
Quick Start:

In standby mode, press START/+30sec repeatedly to set cooking time (up to 95 minutes) at HIGH power. The oven will start automatically.

Grill Cooking:
  1. Place food in the oven.
  2. Press GRILL/COMBI.
  3. Use TIME or +10 min to set cooking time (up to 95 minutes).
  4. Press START/+30sec to begin.
Convection Cooking:
  1. Place food in the oven.
  2. Press OVEN to select desired temperature (110℃-200℃).
  3. Use TIME or +10 min to set cooking time (up to 95 minutes).
  4. Press START/+30sec to begin.
Auto Cook:
  1. Place food in the oven.
  2. Select the desired Auto Cook menu code by pressing the corresponding pad.
  3. Press SERVES 2/3/4 to enter the amount of food.
  4. Press START/+30sec to begin.

Troubleshooting and error codes

Issue
If the oven fails to operate:
1. Check to ensure that the oven is plugged in securely. If it is not, remove the plug from the outlet, wait 10 seconds, and plug it in again securely.
2. Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to be operating properly, test the outlet with another appliance.
3. Check to ensure that the control panel is programmed correctly and the timer is set.
4. Check to ensure that the door is securely closed engaging the door safety lock system. Otherwise, the microwave energy will not flow into the oven.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT A QUALIFIED TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE OVEN YOURSELF.
