Brand: TOSHIBA
Category: Telephone
Document Type: Parts/Service
Language: EN
Parts/Service for TS605 / TS2050
Uploaded: Nov. 21, 2025, 6:23 p.m.
Manual Publish Date: 2006-11-22
Warranty Information
Warranty information is not explicitly detailed in this portion of the manual.
The TS605/TS2050 is a slim and stylish 2.5G handset with a 1.3-megapixel camera, 1.93" TFT display, and Bluetooth connectivity. It supports microSD cards up to 1GB, FM radio with RDS, and various messaging features like MMS, SMS, and Email. The handset has a single external connector for headset, charger, and PC connectivity. Basic operations include inserting SIM and memory cards, and charging the battery. The manual outlines specifications for hardware, software, physical features, video capabilities, and other functions. Troubleshooting guides and repair procedures are also detailed.
Troubleshooting and error codes
| Trouble | Possible Cause | Solution |
|---|---|---|
| 7.1.1 NO POWER UP | PCB dead or CMOS has broken | Restore factory setting, Re-Download, Check CMOS FPC and PCBA, Check Camera module |
| 7.1.2 FLASH FAILED | PCB dead or CMOS has broken | Restore factory setting, Re-Download, Check CMOS FPC and PCBA, Check Camera module |
| 7.1.3 WILL NOT READ SIM CARD | SIM Card Faulty | Check SIM Card; Replace SIM Card |
| 7.1.4 POOR SERVICE | Antenna issue or Signal issue | Check Antenna connection; Change Antenna; Check signal strength |
| 7.1.5 WILL NOT CHARGE | Battery or Charger Faulty | Check Battery; Replace Battery; Check Charger; Replace Charger |
| 7.1.6 LCD FAILURE | LCD connection or LCD Module Faulty | Check LCD Connector; Replace LCD Module |
| 7.1.7 BUZZER FAULT | Buzzer connection or Buzzer Faulty | Check Buzzer connection; Replace Buzzer |
| 7.1.8 VIBRATOR FAULT | Vibrator connection or Vibrator Faulty | Check Vibrator connection; Replace Vibrator |
| 7.1.9 FAULTY KEYPAD | Keypad connection or Keypad Faulty | Check Keypad FPC; Replace Keypad Module |
| 7.1.10 FAULTY RTC | RTC component issue | Replace RTC |
| 7.1.11 FAULTY MICROPHONE | Microphone connection or Microphone Faulty | Check Microphone connection; Replace Microphone |
| 7.1.12 LCD TESTING | N/A | Refer to Section 7.1.6 |
| 7.1.13 FAULTY CAMERA | PCB dead or CMOS has broken | Restore factory setting, Re-Download, Check CMOS FPC and PCBA, Check Camera module; Repair ACF CMOS FPC; Change Camera module |
