Brand: TOSHIBA
Category: DVD Player
Document Type: Manual
Language: EN
Manual for SD-63HK
Uploaded: Nov. 21, 2025, 8:55 p.m.
Manual Publish Date: 2003-09-26
Warranty Information
No warranty information is available in the provided pages.
- Connect the unit to your TV, VCR, radio, or other equipment using the appropriate cables.
- Install batteries in the remote control.
- Turn on the unit and TV.
- Load a disc into the disc tray.
- Use the remote control to play, pause, stop, skip tracks, and access menus.
- Adjust settings such as audio, picture, and language preferences via the setup menu.
- The unit can also be used to listen to the radio.
Troubleshooting and error codes
| Symptom | Cause | Correction | Page |
|---|---|---|---|
| No power. | The mains lead is disconnected. | Connect the mains lead securely into the wall outlet. | – |
| No picture. | The TV is not set to receive DVD signal output. | Select the appropriate video input mode on the TV so the picture from the unit appears on the TV screen. | 12 |
| The scart or video lead is not connected securely. | Connect the scart or video lead securely into the appropriate socket. | 12,13 | |
| The operation mode is not correct. | Select the correct operating mode. | 25,36 | |
| The VIDEO OUTPUT selector is not set correctly. | Set the VIDEO OUTPUT selector to the appropriate position. | 12 | |
| The INPUT SELECT is not set correctly. | Set the INPUT SELECT to the appropriate position. | 38 | |
| No sound. | The scart or audio lead is not connected securely. | Connect the scart or audio lead securely into the appropriate sockets. | 12,13 |
| The unit is in the special playback mode. | Resume the normal playback. | 26 | |
| The operation mode is not correct. | Select the correct operating mode. | 25,36 | |
| The speaker connections are not set correctly. | Connect the speaker lead or wires correctly. | 14 | |
| The volume is set to minimum. | Adjust the volume level. | 25 | |
| The playback picture has occasional distortion. | The disc is dirty. | Eject the disc and clean it. | 5 |
| It is in fast forward or fast reverse playback. | Sometimes a small amount of picture distortion may appear. This is not a malfunction. | – | |
| The DVD video player does not start playback. | No disc is inserted. | Insert a disc. | 25 |
| An unplayable disc is inserted. | Insert a playable disc. (Check the disc type and colour system.) | 6 | |
| The disc is placed upside down. | Place the disc with the playback side down. | 25 | |
| The disc is not placed within the guide. | Place the disc correctly inside the guide on the disc tray. | 25 | |
| The disc is dirty. | Eject the disc and clean it. | 5 | |
| The parental lock function is set. | Cancel the parental lock function or change the parental lock level. | 23 | |
| Playback does not follow the course of the disc's programme. | ✓ appears on the screen. | The function is prohibited with the unit or the disc. | 6 |
| It is in the mode of repeat playback, programme playback, etc. | These operations may prevent a proper progress of the contents. | – | |
| Buttons do not work. | Power supply fluctuations or other abnormalities such as static electricity may interrupt correct operations. | Turn the power on or off with ON/ STANDBY. Or disconnect the power plug and insert it into the wall outlet again. | – |
| The remote control does not work properly. | The remote control is not pointed at the remote sensor of the unit. | Point the remote control at the remote sensor of the unit. | 11 |
| The remote control is too far from the unit. | Operate the remote control within about 7 m. | 11 | |
| The batteries in the remote control are exhausted. | Replace the batteries with new ones. | 11 |
