Warranty Information

Sony will not be liable for damages of any kind resulting from failure to implement proper security measures.

Basic Operation Summary

Attaching and Adjusting the Viewfinder:

  • Loosen positioning rings, attach viewfinder to shoe, tighten rings.
  • Connect viewfinder to VF connector.
  • Adjust viewfinder position using rings and lever.
  • Rotate viewfinder barrel or raise eyepiece for different viewing angles.
  • Use MIRROR switch to reverse image display if needed.

Attaching the Lens:

  • Power off the camera before attaching the lens.
  • Align center pin, insert lens into mount, and lock with lever.
  • Connect lens cable and secure with clamps.
  • Adjust flange back by using the flange focal length adjustment chart.

Preparing the Audio Input:

  • Attach the microphone to the holder.
  • Connect microphone cable to AUDIO 1 IN connector.
  • Set the audio input selector and input level according to the microphone.
