Manual for XL 532

Manual for XL 532

Brand: SIEMENS

Category: Washing Machine

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:05 p.m.

Warranty Information

None

1. Select a programme: Switches the washing machine on/off. Can be rotated in either direction. The programme selector does not rotate while the programme is running; the programme sequence is electronically controlled. 2. Indicator lights: Indicate programme selection (On), active status (Active), programme completion (End), or operation errors (flashing). 3. Set the spin speed: Variable; must click into place at Ø. 4. Press buttons for additional options: Options include reduced programme duration (☃) or an extra rinse cycle (☂). Additional options can be combined before starting the programme. 5. Press the Start button: Starts the washing process after a programme has been selected. Before First Use: Run an empty cycle with detergent and water to remove any residual testing water. Preparing Laundry: Empty pockets, brush out sand, close zippers, tie up curtains, and wash small/delicate items in a net bag. Turn trousers and knitwear inside out. Sorting Laundry: Sort by colour (whites separate from colours) and degree of dirt (slight, normal, intensive). Loading Laundry: Unfold and place items loosely, mixing large and small items. Do not exceed the recommended load. Detergents and Additives: Dispense correctly based on water hardness, laundry amount, and soiling. Too little leads to poor cleaning; too much causes excessive foam.

Troubleshooting and error codes

Fault Possible Cause Remedy
Machine does not start. Mains plug not plugged in. Plug in.
Fuse blown. Check fuse.
Door not closed properly. Close door.
Programme not selected. Select programme.
Water does not enter. Water tap not turned on. Turn on water tap.
Water supply hose bent or squashed. Straighten hose.
Supply hose not connected correctly. Connect correctly.
Water does not drain / spin cycle is not performed. Drain filter blocked. Clean drain filter.
Drain hose bent or squashed. Straighten hose.
Drain hose clogged. Clean drain hose.
Excessive foam. Too much detergent used. Use less detergent.
Detergent not suitable for the machine. Use washing machine detergent.
Door cannot be opened. Programme not finished. Wait until programme is finished.
Safety lock engaged. Wait approx. 2 minutes.
End control light flashes. Possible fault. Refer to manufacturer's instructions or contact customer service.
