Manual for KG..N..

Manual for KG..N..

Brand: SIEMENS

Category: Refrigerator

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:50 p.m.

Warranty Information

The warranty period and terms vary by location. Contact customer service or retailer for details.

Basic operation

Switching on the appliance

  1. Electrically connect the appliance.
  2. Switch off the warning tone using alarm.
  3. Set the required temperature.

Operating tips

  • Wait for the appliance to reach the set temperature before storing food.
  • The front panels may be temporarily warm.
  • The door may be difficult to open immediately after closing due to a vacuum.

Additional functions

Super cooling

Switches on Super cooling before placing large quantities of food.

Automatic Super freezing

Cools the freezer compartment to a lower temperature for faster freezing.

Manual Super freezing

Cools the freezer compartment as cold as possible for freezing large quantities of food.

Holiday mode

Energy-saving mode for when the appliance is not in use.

Energy-saving mode

Saves energy by automatically setting temperatures.

Freshness mode

Keeps food fresh for longer by automatically setting temperatures.

Sabbath mode

Switches off non-essential functions for religious observances.

Alarm

Door alarm

Warns if the appliance door is open for too long.

Temperature alarm

Warns if the freezer compartment becomes too warm.

Troubleshooting and error codes

Fault Cause and troubleshooting
The appliance is not cooling, the displays and lighting are lit. Showroom mode is switched on.
1. Press and hold super (Refrigerator compartment) for 9-11 seconds until an audible signal sounds.
2. After a short time, check whether your appliance is cooling.
The LED lighting does not work. Different causes are possible.
► Call customer service. The customer service number can be found in the enclosed customer service directory.
Side panels of the appliance are warm. Not a fault. The side panels contain pipes which heat up during the cooling process. Units touching the appliance will not be damaged by the heat.
No action required.
A warning tone sounds and the temperature display (refrigerator compartment) and alarm flash. The door alarm is switched on. The refrigerator compartment door is open.
► Close the refrigerator compartment door.
A warning tone sounds and the temperature display (freezer compartment) and alarm flash. The door alarm is switched on. The freezer compartment door is open.
► Close the freezer compartment door.
The temperature displays and alarm light up. A sensor is defective.
► Call customer service. The customer service number can be found in the enclosed customer service directory.
A warning tone sounds and the set temperature (freezer compartment) and alarm flash. The temperature alarm is switched on. Different causes are possible.
► Press alarm.✓ The alarm is switched off.
External ventilation openings are covered up.
► Remove any obstructions from in front of the external ventilation openings.
Larger quantities of fresh food have been put in.
► Do not exceed the max. freezing capacity. → "Freezing capacity", Page 20
The set temperature is not reached. The freezer compartment door was open for a long time. The evaporator (refrigeration unit) in the noFrost system is heavily iced up.
Requirement: Store the frozen food well insulated in a cool place.
1. Switch off the appliance. → Page 16
2. Disconnect the appliance from the mains. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box.
3. Call customer service. The customer service number can be found in the enclosed customer service directory.
Fully automatic defrosting no longer works. Different causes are possible.
1. Switch off the appliance. → Page 16
2. Switch the appliance back on after five minutes. → Page 15– If the temperature is too warm, check the temperature again after a couple of hours. If the temperature is too cold, check the temperature again on the following day.
The temperature differs greatly from the setting. Different causes are possible.
1. Switch off the appliance. → Page 16
2. Switch the appliance back on after five minutes. → Page 15– If the temperature is too warm, check the temperature again after a couple of hours. If the temperature is too cold, check the temperature again on the following day.
Condensation accumulates on the surface of the appliance and on the shelves inside. The water contained in warm and humid air condenses on the colder surfaces of the appliance.
1. Wipe away the water with a soft, dry cloth.
2. Open the appliance as briefly as possible.
3. Ensure that the appliance is always closed properly.
A large volume of condensation collects regularly in the fruit and vegetable container. Depending on the food and quantity stored, condensation may form in the fruit and vegetable container.
1. Remove the fruit and vegetable container. → Page 23
2. Remove the ventilation clips ① and rotate them before inserting again ②.
The appliance hums, bubbles, buzzes, gargles, clicks or crackles. Not a fault. A motor is running, e.g. refrigerating unit, fan. Refrigerant flows through the pipes. The motor, switches or solenoid valves are switching on or off. Automatic defrosting is running. No action required.
The appliance makes noises. The appliance is not level.► Align the appliance using a spirit level and the screw feet.
The appliance is not free-standing.► Observe the minimum clearances for the appliance.
Fittings wobble or stick.► Check the removable fittings and, if required, replace these.
Bottles or containers are touching.► Move the bottles or containers away from each other.
Super freezing is switched on. No action required.
