Parts/Service for S25 / S2588

Parts/Service for S25 / S2588

Brand: SIEMENS

Category: Mobile Phone

Document Type: Parts/Service

Language: EN

Uploaded: Nov. 21, 2025, 8:25 p.m.

Warranty Information

This manual provides service information for the S25/S2588, not warranty details.

Basic Operation

This manual details the service and repair procedures for the Siemens S25 and S2588 mobile phones. It covers mechanical disassembly and assembly, hardware concepts, software programming, battery information, unblocking procedures, and accessories.

Key operational aspects include:

  • Mechanical Handling: Instructions for opening and reassembling the phone without screws, using a case opener.
  • Hardware: Overview of the block diagram and descriptions of major integrated circuits like HiGOLD, GOLD-SX, GAIM, Receiver Circuit, and Transmitter Circuit.
  • Software: Steps for updating software and programming customer-specific initialisations, including language group selection.
  • Battery: Details on battery specifications, charging, short-circuit protection, and datecodes.
  • Unblocking: Procedures for unblocking the phone using the Siemens Hotline or an internet solution.
  • Accessories: A comprehensive list of available accessories for the S25/S2588.

Troubleshooting and error codes

ProblemPossible CauseSolution
Phone does not turn on (deeply discharged battery) Battery voltage too low to operate charging circuit and display controller. 1. Connect travel charger for trickle charge (approx. 1 hour).
2. Disconnect and reconnect charger.
3. If voltage is sufficient, charging symbol appears and phone can be turned on.
*Deeply discharged batteries may require up to 24 hours for trickle charge.
Phone does not turn on (battery short-circuit protection activated) Electronic fuse activated due to high current. Procedure 1:
1. Insert battery into S25, connect rapid charger. Wait 10 sec. Phone can be turned on.
Procedure 2:
1. Plug battery into desktop charger. Fuse resets immediately.
Overvoltage Condition (Battery Voltage) Supply voltage rises above 6.2 Volts. Phone will switch off and cannot be switched on until voltage is below 6.2 Volts. If voltage rises above 7 Volts, the phone can be destroyed.
Overvoltage Condition (Charging Current) Charging current rises above 1 A. Phone fuse will be inoperable, and charging will not be possible.
