Manual for QW-T13F491W-EU

Manual for QW-T13F491W-EU

Brand: SHARP

Category: Home Appliances

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:25 p.m.

Warranty Information

Refer to the warranty card for warranty information.

Switching on the machine

  1. Press the Power On/Off key.
  2. Select the program suiting your dishes via the Program Selector button.
  3. If you prefer or wish to prefer, you can choose additional function.
  4. Start the program pressing the Power Start/Pause key.

Program follow-up

You can follow the program flow using the program follow-up lamps located on the control panel. As long as Washing and Drying goes on the Washing/Drying light not lamp stays lit. When drying is active machine stays silent about 40-50 minutes. Once the program is over, the finished light is illuminated. Do not open the cover until the Finished light is on.

Changing a programme

If you would like to change programs while a washing program is continuing: After the program stops, select your desired program via the Program selector button. Press the power Start/Pause key once. Start the program you have newly selected by pressing again the Start/Pause key. The new program started will resume the course of the old program.

Changing a programme with resetting

If you would like to cancel a program while a washing program is resumed: Hold Start/Pause button pressed for approx. 3 sec. until Finish light blinks. After Finish light starts blinking, discharges the water inside for approx. 30sec. Once Finish light comes on, it means that the cycle has been cancelled.

Switching the machine off

When the light illuminates lamp "End" lights up, switch your machine off by using the Power On/Off button. Pull the plug out of the outlet. Turn of the water tap.

Troubleshooting and error codes

ERROR CODE ERROR DESCRIPTION CONTROL
F5 Inadequate water supply
  • Make sure the water input tap is totally open and that there is no water cut.
  • Close the water input tap, separate the water input hose from the tap and clean the filter at the connection end of the hose.
  • Restart your machine, contact the service if the error resumes.
F3 Error of continuous water input
  • Close the tap.
  • Contact service.
F2 The waste water in the machine cannot be discharged.
  • Water discharge hose is clogged.
  • The filters of your machine might be clogged.
  • Power off-on your machine and activate the program cancellation command.
  • If the error continues, contact the service.
F8 Heater error
  • Contact service.
F1 Alarm is active against water overflow
  • Power off your machine and close the tap.
  • Contact service.
FE Faulty electronic card
  • Contact service.
F7 Overheating error (temperature in the machine is too high)
  • Contact service.
F9 Divisor position error
  • Contact service.
F6 Faulty heater sensor
  • Contact service.
