Parts/Service for PDP-42H1EV
Uploaded: Nov. 21, 2025, 9:02 p.m.
SAFETY PRECAUTIONS: To reduce the risk of fire or electric shock, do not expose the appliance to rain or moisture. Ensure proper ventilation. Unplug the unit when not in use for extended periods.
CAUTION IN INSTALLING: Handle carefully, avoid dropping. Locate away from heat, excessive dust, and direct sunlight. Use trained personnel for installation.
PRODUCT SAFETY NOTICE: When replacing components, use exact replacements, especially for parts marked with A.
Troubleshooting and error codes
| No. | Adjustment Name | Adjustment Item | Initial Data | Data Area | Note | |
| 0 | AV-Dynamic | Contrast | 63 | 0 | 63 | Picture Menu (Dynamic) |
| 1 | Brightness | 31 | 0 | 63 | ||
| 2 | Color | 42 | 0 | 63 | ||
| 3 | Tint | 0 | -31 | 32 | ||
| 4 | Sharpness | 15 | 0 | 30 | ||
| 5 | AV Standard | Contrast | 50 | 0 | 63 | Picture Menu (Natural) |
| 6 | Brightness | 31 | 0 | 63 | ||
| 7 | Color | 31 | 0 | 63 | ||
| 8 | Tint | 0 | -31 | 32 | ||
| 9 | Sharpness | 15 | 0 | 30 | ||
| 10 | AV Cinema | Contrast | 37 | 0 | 63 | Picture Menu (Cinema) |
| 11 | Brightness | 32 | 0 | 63 | ||
| 12 | Color | 22 | 0 | 63 | ||
| 13 | Tint | 0 | -31 | 32 | ||
| 14 | Sharpness | 13 | 0 | 30 | ||
| 15 | PC Graphic | Contrast | 63 | 0 | 63 | Picture Menu (Graphic) |
| 16 | Brightness | 31 | 0 | 63 | ||
| 17 | Color | 45 | 0 | 63 | ||
| 18 | Tint | 0 | -31 | 32 | ||
| 19 | ||||||
| 20 | PC Standard | Contrast | 40 | 0 | 63 | Picture Menu (Standard) |
| 21 | Brightness | 31 | 0 | 63 | ||
| 22 | Color | 31 | 0 | 63 | ||
| 23 | Tint | 0 | -31 | 32 | ||
| 24 | ||||||
| 25 | PC-Text | Contrast | 31 | 0 | 63 | Picture Menu (Text) |
| 26 | Brightness | 31 | 0 | 63 | ||
| 27 | Color | 26 | 0 | 63 | ||
| 28 | Tint | 0 | -31 | 32 | ||
| 29 | ||||||
| 30 | Sub Menu AV | Contrast | 6Bh | 00h | FFh | Composite, S-Video |
| 31 | Brightness | 33h | 00h | FFh | ||
| 32 | Color-S | 78h | 00h | FFh | S-Video | |
| 33 | ||||||
| 34 | Tint | FFh | 80h | 7Fh | ||
| 35 | Sharpness | 0Fh | 00h | 1Fh | 0Fh=9415add.5Dh:78h | |
| 36 | Sub Menu PC | Contrast | 61h | 00h | FFh | |
| 37 | Brightness | 32h | 00h | FFh | ||
| 38 | Color | 80h | 00h | FFh | ||
| 39 | Tint | 00h | 80h | 7Fh | ||
| 40 | Sharpness | 40h | 00h | FFh | ||
| 41 | Sub Menu AV-D2-D4 | Contrast | 5Bh | 00h | FFh | D2-4 Input |
| 42 | Brightness | 32h | 00h | FFh | ||
| 43 | Color | 80h | 00h | FFh | ||
| 44 | Tint | FAh | 80h | 7Fh | ||
| 45 | Sharpness | 40h | 00h | FFh | ||
| 46 | Sub Menu AV-D1 | Contrast | 6Dh | 00h | FFh | D1 Input (480i) |
| 47 | Brightness | 33h | 00h | FFh | ||
| 48 | Color | Coh | 00h | FFh | ||
| 49 | Tint | 00h | 80h | 7Fh | ||
| 50 | Sharpness | 0Ch | 00h | 1Fh | 0Fh=9415add.5Dh:78h | |
| 51 | Color Temp H-AV | Red | DCh | 00h | FFh | AV Color Temperature (High) |
| 52 | Green | Foh | 00h | FFh | ||
| 53 | Blue | FFh | 00h | FFh | ||
| 54 | Color Temp M-AV | Red | FFh | 00h | FFh | AV Color Temperature (STD) |
| 55 | Green | FFh | 00h | FFh | ||
