HOTEL MODE
To enter Hotel Mode press and hold the green button on the remote control for 3 seconds. Hotel Mode allows the user to set up the function of the set.
- Hotel mode: ON/OFF
- On program: OFF/1~99/AV1-AV3/RGB/HDMI/PC
- Preset: ON/OFF
- Address: 007
- Baud Rate: 19200
SERVICE MODE
To enter Service Mode press and hold the green button on the remote control whilst pressing the PV button on the tv cabinet at the same time, alternatively:-
From Hotel Mode press and hold the green button on the remote control for 3 seconds
To select the service item and change data value
- To select the adjustment item, use the PA or PV buttons.
- To change the service data, use the Volume - (LEFT) or Volume + (RIGHT) buttons.
- The data which is set in the service mode is stored into the memory IC automatically
EXAMPLE:
000 UK4B 07.45
ITEM NO SECTION ITEM VALUE
EXIT FROM THE SERVICE MODE
- Press the MENU button or turn off the TV set by using the Mains switch.
Troubleshooting and error codes
| Item | Condition | Check point |
|---|---|---|
| 1 No power | NO LED | Check to voltage of KR-3 --- 5V >>Change the power board |
| 2 No power | NO LED | Check the fuse on the FILTER board |
| 3 No power | LED brighter | Check the connection of the AC cord. (AC plug and junction part) |
| 4 No backlight | After power on, once panel lights then keep black out | Change the LCD panel |
| 5 Faulty picture | No colour, poor picture Darker / brighter picture etc. | Change the COMP board >>If not, change the panel. |
| 6 Faulty picture | Visible line on the picture Part of the display is poor | Change the panel |
| 7 No RC | No working of RC handset | Change the RC or FRONT board |
| 8 No key SW | No working or the front key Switch | Change the FRONT board |
| 9 Fan faulty | After indication of the display, then 30 seconds later, come into standby | Change the FAN |
