Brand: SANYO
Category: Commercial Solutions
Document Type: Manual
Language: EN
Manual for PLC-XP200L
Uploaded: Nov. 21, 2025, 8:49 p.m.
Warranty Information
Warranty information is not explicitly stated as a period in the provided pages.
Basic Operation
Turning On the Projector: Press the ON/STAND-BY button to turn the projector on. The POWER indicator will light green.
Turning Off the Projector: Press the ON/STAND-BY button to turn the projector off. The POWER indicator will blink, and the projector will enter standby mode. Allow for cooling down.
On-Screen Menu: Press the MENU button to open or close the On-Screen Menu. Use the POINT buttons to select items or adjust values. Press the SELECT button to execute.
Input Selection: Press the INPUT button to select the desired input source (Computer, Video, etc.).
Remote Control: The remote control can be used wirelessly or wired. Functions include power on/off, input selection, menu navigation, volume adjustment, and special features like Auto PC Adjustment and Shutter.
Troubleshooting and error codes
| POWER green | LAMP/ SHUTTER red/blue | WARNING TEMP. red | WARNING FILTER orange | LAMP REPLACE orange | Projector Condition |
|---|---|---|---|---|---|
| ⚪ | ♦ | ⚪ | * | * | The temperature inside the projector is elevated close to the abnormally high level. |
| ⚫ | ♦ | ⚫ | * | * | The temperature inside the projector is abnormally high. The projector cannot be turned on. When the projector is cooled down enough and the temperature returns to normal, the POWER indicator lights green and the projector can be turned on. (The WARNING TEMP. indicator keeps blinking.) Check and replace the filter. |
| ⚪ | ♦ | ⚫ | * | * | The projector has been cooled down enough and the temperature returns to normal. When turning on the projector, the WARNING TEMP. indicator stops blinking. Check and replace the filter. |
| ⚪ | ♦ | ⚪ | * | * | The lamp cannot light up. (The projector is preparing for stand-by or the projection lamp is being cooled down. The projector cannot be turned on until cooling is completed.) |
| ⚪ | ♦ | ⚪ | ⚫ | * | The lamp cannot light up. (The lamp has been cooled down enough and the projector is in stand-by mode and ready to be turned on with the ON/STAND-BY button.) |
| ⚫ | ⚫ | ⚫ | ⚫ | ⚫ | The lamp has been used overtime. Replace the lamp immediately and then reset the lamp counter. The indicator will be turned off after resetting the counter. |
| ⚪ | ⚫ | ⚪ | ⚫ | * | If the Filter counter reached a time set in the timer setting, a Filter replacement icon (Fig.2) appears on the screen and the WARNING FILTER indicator on the top panel lights up. Replace the filter as soon as possible. If the filter is out of scroll and the projector reaches a time set in the timer setting, Fig. 3 appears on the screen and the WARNING FILTER indicator lights up. Replace the filter cartridge as soon as possible. |
| ⚪ | ⚫ | ⚪ | ⚫ | ⚫ | If the filter is clogged and no scroll is left in the filter cartridge, a Filter cartridge replacement icon (Fig.4) appears on the screen and the WARNING FILTER indicator lights up. Replace the filter cartridge as soon as possible. |
| ⚪ | ⚫ | ⚫ | ⚫ | * | The filter cartridge is not installed in the projector. Check the filter compartment to see if the filter cartridge is installed in the projector. When the filter cartridge is installed and the indicators continue to light and blink, read the column below. |
| * | ⚫ | ⚫ | * | * | The projector detects an abnormal condition and cannot be turned on. Unplug the AC power cord and plug it again to turn on the projector. If the projector is turned off again, unplug the AC power cord and contact the dealer or the service center. Do not leave the projector on. It may cause an electric shock or a fire hazard. |
| ⚫ | ⚫ | ⚫ | ⚫ | ⚫ | The shutter is out of control. |
| ⚪ | ⚫ | ⚫ | ⚫ | * | The shutter is out of control. (The projector is in the cooling mode.) |
| ⚪ | ⚫ | ⚫ | ⚫ | * | The shutter is out of control. (The projector is in the stand-by mode.) In that case, contact the service station immediately. |
