Brand: SANYO
Category: Camcorder
Document Type: Manual
Language: EN
Manual for VPC-GH3EX
Uploaded: Aug. 10, 2025, 12:14 a.m.
Basic Operation
Shooting:
- Press the ON/OFF button for at least 1 second to turn the camera on.
- To record a video clip, press the [] button to begin and press it again to end.
- To take a photo, press the [] button.
Playback:
- Press the REC/PLAY button to enter Playback Screen.
- Use the arrow keys to select an image.
- Press the SET button to begin playback.
Deleting files:
- In Playback Screen, move the orange frame to the file to delete and press the MENU button.
- Select "DELETE", then "DELETE SINGLE", and press the SET button.
Copying data to computer:
- Connect camera to computer using the USB interface cable.
- Turn on both devices.
- On the camera's USB Connection Screen, select "COMPUTER" then "CARD READER" and press SET.
- Copy files from the camera's drive ([Xacti] or [Xacti_INT]) to the computer.
Dismounting camera:
- Safely remove hardware icon in the task tray.
- Left-click on the camera drive.
Troubleshooting and error codes
| Question | Answer | Action |
|---|---|---|
| Misc. | The "Cannot edit video clips with unlike settings" message appears. | You have attempted to join video clips having different resolutions or frame rates. Select video clips that have the same resolution or frame rate. |
| Why is a noise heard from a nearby TV or radio during battery recharging? | Electromagnetic waves are emitted from the charger. | Move the AC adaptor further away from the TV or radio when recharging the battery pack. |
| Why does the "Insufficient card memory" or "Insufficient internal memory” message appear? | There is no more available memory on the card or in the camera's internal memory. | Delete unnecessary files, or use a card that has more memory available. |
| Why does the "Card is protected" message appear? | The lock switch on the card is in the locked (protect) position. | Move the lock switch to the unlocked position. |
| Why can't the camera be operated? | A temporary internal circuitry problem may be the cause. | Remove the AC adaptor (optional) and the battery pack from the camera, wait a few minutes, then reinstall the battery pack and try again. |
| A problem such as inability to record or play back occurs. | The card contains files that were saved using a device other than this camera. | After saving your files to a different medium, format the card. |
| Misc. | Can I use my camera abroad? | When the camera is connected to a TV, you can switch the camera's video output to NTSC or PAL. If you have questions about accessories etc., please consult with a dealer near you for advice. |
| Why does the "System error” message appear? | A problem has occurred within the camera or card. | Check the following items: ① Remove the card and then install it again. ② Remove the battery pack and then install it again. ③ Install a different card. If "System error” still appears after performing the above steps, then take the camera to the dealer for service. |
