Warranty Information

Sanyo Fisher Company warrants this product against defects in materials and workmanship for 3 years.

Basic Operation Summary

This section covers the initial setup and operation of the SANYO VCC-3944 Color CCD camera. It details connecting the power supply and video signal, inserting the power cord, and adjusting picture settings like brightness and contrast. The manual also provides instructions for mounting lenses, including DC type auto-iris lenses, and explains the flange-back adjustment for optimal focus. Various camera settings are detailed, such as Electronic Iris (EI)/Auto Iris (AI), Gain up, Backlight Compensation (BLC), White Balance, Synchronization, and Lens Iris adjustment, with specific switch positions and their effects described to achieve desired image quality under different lighting conditions.

Troubleshooting and error codes

Problem	Possible Cause & Solution
No picture on the monitor screen	Is the power turned on to all connected devices? Is the voltage correct? Are all the signal connecting cables correctly connected? Is the lighting sufficient? Has the lens cap been removed? Is the iris control correctly set?
The picture is not clear	Is the monitor correctly adjusted? Is the flange-back position correctly set? Is the lens focus correctly adjusted? Are the lens surfaces clean? (Clean with a soft cloth or lens cleaning set.)
