Manual for HT-Z320

Manual for HT-Z320

Brand: SAMSUNG

Category: Home Cinema

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 9:14 p.m.

Features

  • Plays various disc types including DVD-VIDEO, CD, MP3-CD, WMA-CD, DivX, CD-R/RW, and DVD±R/RW.
  • USB Host support for playing media files from USB storage devices.
  • Dolby Pro Logic II for multi-channel audio decoding.
  • DTS (Digital Theatre Systems) for full-frequency 5.1 channel sound.
  • TV Screen Saver Function and Power Saving Function to conserve energy.
  • Customized TV Screen Display to set background wallpaper.
  • Anynet+ (HDMI-CEC) Function for operating the unit with a Samsung TV remote.
  • AV SYNC Function to adjust audio delay for synchronization with video.

What's Included

Check for the supplied accessories: Video Cable, FM Antenna, User's Manual, Remote Control/Batteries (AAA size).

Troubleshooting and error codes

SYMPTOM Check/Remedy
Disc tray does not open.
  • Is the power cord plugged securely into the outlet?
  • Turn off the power and then turn it back on.
Playback does not start immediately when the Play/Pause button is pressed.
  • Are you using a deformed disc or a disc with scratches on the surface?
  • Wipe the disc clean.
Sound is not produced.
  • No sound is heard during fast playback, slow playback, and step motion playback.
  • Are the speakers connected properly? Is the speaker setup correctly customized?
  • Is the disc severely damaged?
Sound can be heard only from a few speakers and not all six.
  • When listening to a CD or radio, sound is output to the front speakers (L/R) only. Select "PRO LOGIC II" by pressing DOLBY PRO LOGIC II on the remote control to use all six speakers.
  • Make sure that the DVD disc is 5.1-CH compatible.
  • If you set C, SL, and SR to NONE in the speaker mode in the audio setup of the setup screen, no sound is heard from the centre speaker and the front left and right speakers. Set C, SL, and SR to SMALL.
Dolby Digital 5.1 CH Surround Sound is not produced.
  • Is there "Dolby Digital 5.1 CH" mark on the disc? Dolby Digital 5.1 CH Surround Sound is produced only if the disc is recorded with 5.1 channel sound.
  • Is the audio language correctly set to DOLBY DIGITAL 5.1-CH in the information display?
The remote control does not work.
  • Is the remote control being operated within its operation range of angle and distance?
  • Are the batteries exhausted?
  • Have you selected the mode(TV/DVD) functions of the remote control (TV or DVD) correctly?
• Disc is rotating but no picture is produced.
  • Is the TV power on?
  • Are the video cables connected properly?
  • Is the disc dirty or damaged?
  • A poorly manufactured disc may not be playable.
• Picture quality is poor and picture is shaking.
Audio language and subtitles do not work.
  • Audio language and subtitles will not work if the disc does not contain them.
Menu screen does not appear even when the menu function is selected.
  • Are you using a disc that does not contain menus?
Aspect ratio cannot be changed.
  • You can play 16:9 DVDs in 16:9 WIDE mode, 4:3 LETTER BOX mode, or 4:3 PAN SCAN mode, but 4:3 DVDs can be seen in 4:3 ratio only. Refer to the DVD disc jacket and then select the appropriate function.
• The main unit is not working. (Example: The power goes out or the front panel key doesn't work or a strange noise is heard.) • The DVD player is not working normally.
  • Turn off the power and hold the STOP (■) button on the remote control for longer than 5 seconds (reset function). Using the RESET function will erase all stored settings. Do not use this unless necessary.
The rating level password has has been forgotten.
  • While "NO DISC" message appears on the display of the main unit, hold the remote control's STOP (■) button for longer than 5 seconds. "INITIAL" appears on the display and all settings will return to the default values.
  • Press the POWER button. Using the RESET function will erase all stored settings. Do not use this unless necessary.
Can't receive radio broadcast.
  • Is the antenna connected properly?
  • If the antenna's input signal is weak, install an external FM antenna in an area with good reception.
