Warranty Information
This product comes with a one (1) year parts and labor warranty from the original date of purchase.
- Playing a Disc: Press OPEN/CLOSE to open the disc tray, place a disc with the label facing up, then press PLAY/PAUSE or OPEN/CLOSE to close the tray.
- Stopping Playback: Press the STOP button.
- Pausing Playback: Press the PLAY/PAUSE button. Press again to resume.
- Searching & Skipping: Use the SEARCH buttons or Shuttle dial to navigate through the disc.
- Using the Menu: Press the MENU button to access disc, title, or function menus for various options.
- Setup Menu: Press MENU, select Setup to customize language, audio, display, and parental controls.
Troubleshooting and error codes
| Problem | Action | Page |
|---|---|---|
| No operations can be performed with the remote. | Check the batteries in the remote. They may need replacing. Operate the remote control at a distance of no more than 20 feet. Remove batteries and hold down one or more buttons for several minutes to drain the microprocessor inside the remote to reset it. Reinstall batteries and try to operate the remote again. |
P5 |
| Disc does not play. | Ensure that the disc is installed with the label side facing up. Check the region number of the DVD. |
P7 |
| 5.1 channel sound is not being reproduced. | 5.1 channel sound is reproduced only when the following conditions are met.: 1) The DVD player is connected with the proper amplifier 2) The disc is recorded with 5.1 channel sound. Check whether the disc being played has the "Dolby 5.1 ch" mark on the outside. Check if your audio system is connected and working properly. In a SETUP Menu, is the Audio Output set to Bitstream? |
P11, P33 |
| The icon appears on screen. | The features or action cannot be completed at this time because: 1. The DVD's software restricts it. 2. The DVD's software doesn't support the feature (e.g., angles). 3. The feature is not available at the moment. 4. You've requested a title or chapter number or search time that is out of range. |
P15 |
| Disc Menu doesn't appear. | Check if the disc has a Menu. | |
| Play mode differs from the Setup Menu selection. | Some of the functions selected in the Setup Menu may not work properly if the disc is not encoded with the corresponding function. | P30~37 |
| The screen ratio cannot be changed. | The Screen Ratio is fixed on your DVDs. | P35 |
| No audio. | Make sure you have selected the correct Digital Output in the Audio Options Menu. | P33 |
| The screen is blocked | Press power on from a cold start with no disc in the unit. Press the button on the front panel for 5 seconds. The SELECT MENU LANGUAGE display will appear. Select the number button of the desired language. Press the MENU button, and then press DOWN button to select Setup, then press RIGHT or ENTER. Press Up or Down to select Parental Setup The Parental Setup is now unlocked as indicated on the display. You can change your password. |
P35-37 |
| Forgot password | Press power on from a cold start with no disc in the unit. Press the button on the front panel for 5 seconds. The SELECT MENU LANGUAGE display will appear. Select the number button of the desired language. Press the MENU button, and then press DOWN button to select Setup, then press RIGHT or ENTER. Press Up or Down to select Parental Setup The Parental Setup is now unlocked as indicated on the display. You can change your password. |
P36-37 |
| If you experience other problems. | Go to the contents and find the section of the instruction book that contains the explanations regarding the current problem, and follow the procedure once again. If the problem still cannot be solved, please contact your nearest authorized service center. |
|
| No DVI output. | Check the Video output is DVI enabled. Check the connection between the TV and the DVI jack of DVD player. |
P13~14 |
| Abnormal DVI output | See if the TV supports this 480p/720p/768p/1080i DVD player. If snow noise appears on the screen, it means that TV does not support HDCP (High-bandwidth Digital content protection). |
P14 |
