Warranty Information

One year limited warranty on all parts and labor for original U.S. purchasers.

  • Control Panel: Familiarize yourself with the buttons and displays.
  • Simple Steps to Start: Quick guide to begin a drying cycle.
  • Cycle Overview: Learn about different drying cycles available.
  • Cycle Chart: Details on cycle duration and features.
  • SmartThings: Information on connecting your dryer to smart devices.

Troubleshooting and error codes

Problem Action
Dries unevenly.
  • Heavy areas may be slightly damp; select a higher dryness level or cycle.
  • Dry heavy and light items separately.
Has odors.
  • Room air odors can enter the dryer. Ventilate the room before use.
Lint on clothes.
  • Clean lint filter before or during the cycle.
  • Dry lint-producing fabrics separately from lint-trapping fabrics.
  • Divide large loads.
  • Check pockets.
  • Remove lint from drum.
Items still wrinkled after WRINKLE PREVENT (WRINKLE-CARE, WRINKLE RELEASE).
  • Use small loads (1-4 items).
  • Load similar items.
  • Remove items immediately after drying.
Extended time.
  • Sensor Dry adjusts time based on moisture. See cycle chart for details.
Information codes Code Action
dC
  • Ensure door is closed.
  • Ensure laundry is not caught in the door.
FC
  • Invalid power source frequency. Try restarting cycle. Contact service if persists.
AC
  • Electronic control problem. Contact Samsung service center.
HC
  • High temperature heating. Clean lint filter. Contact service if persists.
9C1
  • Electronic control check. Verify power connection and outlet. Contact service if persists.
tC
  • Thermistor1 error. Check lint screen and vent. Contact service if persists.
tC5
  • Thermistor2 error. Check lint screen and vent. Contact service if persists.
dF
  • Incorrect door switch. Contact Samsung service center.
3C
  • PBA needs check. Unplug and contact service center.
