Manual for DV*60M9900* / DV*55M9600*

Manual for DV*60M9900* / DV*55M9600*

Brand: SAMSUNG

Category: Dryer

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 8:25 p.m.

  • Extra Large Capacity: Dry extra-large loads with a 7.5 cu.ft. capacity dryer that circulates more air for faster, wrinkle-free drying.
  • Time Saving: Cycles are designed to dry clothes in as little as 42 minutes.
  • Energy Saving: Super energy efficient, drying up to 3.31 pounds of laundry with 1kWh. Fuzzy Logic Control optimizes drying.
  • Easy Reversible Door: Door can be changed with four screws to fit any location.
  • Pedestal With Storage Drawers: Optional 15" pedestal raises the dryer and offers storage for detergent bottles.
  • Various Drying Cycles & Fuzzy Logic Algorithm: Select from 13 automatic cycles or let Fuzzy Logic measure dampness and set time automatically.
  • Smart Care: Automatic error-monitoring system detects and diagnoses problems, offering quick solutions. Smart Remote Control technology alerts via smartphone.
  • 4-way Vent(Elec.): Vent can be installed in four positions: back, either side, bottom.
  • Delicate Dry: Use "Delicate dry" with tumble dry to protect clothes from high temperature heat.

Troubleshooting and error codes

No Problem What to do
1 Will Not Start or Run
  • All wires are hooked up to their corresponding terminals.
  • Is the dryer is plugged in.
  • Blown fuse or circuit breaker.
  • Is the Door switch functional...door closed. Check for error code 3 (See Table for code definition).
  • Start/Pause rotary selector dial functional.
  • Is the control Board operational.
  • Belt off or broken and Belt Cut-off Switch operates.
  • Is the motor functional.
  • Check motor winding resistance: 2.88ohms between pin #3 and 4, 3.5ohms between pin #4 and 5.
2 Motor runs/ tumbler will not turn
  • Belt off or broken/damaged.
  • Idler tension spring too weak or stretched.
  • Idler pulley jammed or stuck.
3 Runs a few minutes and then stops
  • Lint buildup around drive motor.
  • Low voltage present.
  • Blower impeller blocked in blower housing.
  • Check the actuator of motor.
4 Blows fuses or trips circuit breaker
  • Is the belt connected well?
  • Is the winding of the motor continuous? (Rotor winding, stator winding, generator)
  • Is the motor protector normal?
  • If above points are not found, the PCB assembly is out of order. Replace it.
5 Blows fuses or trips circuit breaker (Gas Model)
  • During ignition the dryer will draw 6 amps. With the burner ON, the dryer will draw 4.5 amps. If the dryer is drawing amperages above this, then the house wiring, fuse box or circuit breaker is suspected to be at fault.
  • Igniter harness loose and shorted to base.
  • Incorrect wiring or wire shorted to ground.
  • Drive motor winding shorting to ground.
6 Will not heat (motor runs)
  • Open heating element.
  • Hi-Limit trips easily or is open.
  • Regulating thermostat trips easily or is open.
  • Membrane switch open.
  • Check Thermistor.
7 Will Not Dry Gas Model Poor Gas Ignition When the dryer is operated on a heat setting, the igniter should be energized and burner shall fire within 45 seconds at 120 VAC. The failure of a component in this system will usually be indicated by one of three symptoms (No.8, No.9, No.10)
8 The igniter does not glow If the igniter does not heat up, remove power and using an ohmmeter, check the following:
  • Open flame sensor
  • Open igniter
  • Shorted booster coil
  • Open wiring
  • Bad motor switch (Neutral supply)
  • No power from control (L1 supply)
9 Igniter glows - No gas ignition If the igniter heats up but the main burner flame is not ignited, remove power and using an ohmmeter, check the following:
  • Open secondary coil
  • Open holding coil
  • Open wire harness
  • Stuck flame sensor (Stuck closed)
10 The gas is ignited but the flame goes out If a normal ignition takes place and after a short while the flame goes out, check for the following:
  • Radiant sensor contacts opening prematurely.
  • Weak gas valve coil may open when stressed by higher Temps.
  • Weak Hi-Limit
  • Poor venting
  • Bad drum seals
11 Improper drying clothes wrinkled Rough texture long dry time
  • The lint filter is not clean.
  • Any restriction in the exhaust.
  • The outside exhaust hood damper door stuck closed.
  • Is the exhaust too long, too many elbows, flex ductwork installed.
  • Poor intake air available for the dryer.
  • Incorrect tumbler speed. Tumbler belt slipping.
  • Blower impeller bound; check for foreign material in blower area.
  • Customer overloading dryer.
  • Check clothing labels for fabric content and cycle selected.
  • Clothes too wet due to insufficient spin out by washer.
12 Noisy and/Or Vibration
  • "Thumping" Check for loose tumbler baffle, rear tumbler roller(s) worn or misaligned, out-of-round tumbler or high weld seam on tumbler.
  • "Ticking" Check for loose wire harness or object caught in blower wheel area.
  • Scraping Check for front or rear bulkhead felt seal out of position or worn tumbler front bearings.
  • "Roaring" Check for blower wheel rubbing on blower housing or bad motor bearings.
  • Popping or squealing sound. Check for a sticky or frayed belt.
