Warranty Information

1-year parts and labor, 5-year for specific components like the circuit board and racks.

Basic Operation of Your Dishwasher

Loading Dishes: Properly load dishes into the upper and lower racks, ensuring items do not obstruct the spray arms. Utilize designated areas like the Storm Wash+ zone for optimal cleaning. The 3rd rack and cutlery rack are for smaller items and flatware.

Selecting a Cycle: Choose from various wash cycles (e.g., Auto, Normal, Heavy, Delicate, Express 60', Plastic, PotsPans, BabyCare, Night, SelfClean) based on your load. Available options like Lower Rack, Storm Wash+, Hi-Temp Wash, Sanitize, SmartDry, and Delay Start can be selected to customize the wash.

Starting the Dishwasher: After loading and selecting a cycle, close the door and press the start button. The dishwasher will begin its cycle, which may include pre-wash, main wash, rinses, and drying phases.

Maintenance: Regularly clean the dishwasher, including the filter and drain pump, to ensure optimal performance. Follow long-term care instructions when the appliance is not in use.

Troubleshooting and error codes

Problem Possible cause Solution
Has a bent upper rack after dishes are loaded. The dishes are not loaded properly.
  • Load your dishes as recommended. (See page 18.)
Cannot close the door. Auto Release™ Dry mode is in operation.
  • Once the door opens in the Auto Release™ Dry mode, the door cannot be closed manually for the next 2 minutes. You may close the door after 2 minutes.

Information codes

Code Action
LC Leakage check.
  • If a water supply valve connection leak occurs, close the water supply valve and go to your house circuit breaker panel, set the dishwasher's circuit breaker switch to off, and then contact the installer to fix.
  • If the problem continues, contact an authorized Samsung service center.
4C Water supply check.
  • Check if the water supply valve is closed or clogged, or is frozen. Also check if the supplied water pressure is less than required.
  • If the problem continues, close the water supply valve, and then contact an authorized Samsung service center.
5C Drain check.
  • After closing the water supply valve, check whether the drain hose is clogged or folded. Also, check whether the drain hole inside the sump is clogged.
  • If the problem continues, contact an authorized Samsung service center.
HC High temperature heating check.
  • Functional check. With the dishwasher empty, add detergent, and then run a cycle. If the problem continues, go to your house circuit breaker panel, set the dishwasher's circuit breaker switch to off, and then contact an authorized Samsung service center.
3C Pump operation check.
  • Functional check. Turn off the dishwasher and try to start it again.
  • If the problem continues, contact an authorized Samsung service center.
PC Zone wash function check.
  • Functional check. Turn off the dishwasher and try to start it again.
  • If the problem continues, contact an authorized Samsung service center.

For any codes not listed above, call 1-800-SAMSUNG (726-7864).
