Brand: SAMSUNG
Category: Camera
Document Type: Parts/Service
Language: EN
Parts/Service for SCL300/L310/L320/L330/L350
Uploaded: Nov. 21, 2025, 7:48 p.m.
Manual Publish Date: 1999-03-01
Warranty Information
Refer to the specific warranty information provided with the product.
Precautions
- Ensure all protective devices and shields are replaced.
- When reassembling, restore all protective devices like knobs and covers.
- Prevent finger access to dangerous voltages by ensuring no cabinet openings.
- Perform leakage current checks, ensuring readings are within specified limits.
- X-ray protection is designed in, replace tubes with identical types.
- Handle semiconductors with care to prevent static discharge damage.
- Always drain electrostatic charge before handling components.
Service Tips
Section 2-1 details replacing the bulb for the video light, providing step-by-step instructions and illustrations.
Troubleshooting and error codes
| Error Code/Symptom | Possible Cause | Remedy |
|---|---|---|
| No Power | Power cord disconnected, outlet issue, internal power supply failure | Check connections, test outlet, inspect power supply components. |
| No Image | Camera malfunction, lens issue, sensor problem | Inspect camera module, clean lens, check sensor connections. |
| Audio Issues | Microphone malfunction, connection problem, internal audio circuit failure | Check microphone connections, test microphone, inspect audio circuitry. |
