Manual for AR**TSFY*WKNCN

Manual for AR**TSFY*WKNCN

Brand: SAMSUNG

Category: Air Conditioner

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:49 p.m.

Warranty Information

No warranty information is available in the provided document sections.

  • Fast Cooling: Provides the strongest cool air.
  • Wind-Free Cooling: Delivers a mild breeze through fine holes, not directly from blades.
  • Motion Detection: Detects people and adjusts airflow; enters energy-saving mode if no motion is detected.
  • Eco Mode (Single User): Minimizes energy consumption by adjusting compressor capacity.
  • Easy Filter: Filter can be easily removed and cleaned without removing the grille.
  • Good'sleep Function: Adjusts temperature, fan speed, and airflow for better sleep.
  • Smart Install: Performs a trial operation to check installation accuracy.
  • Easy Installation: Simplified wall mounting and pipe/wire connection.

Troubleshooting and error codes

ERROR MODE TYPE DESCRIPTION
7-SEG INDOOR/OUTDOOR Communication error
C101, C102 Set address error
C108 Room TH sensor error
C121 INDOOR MID, INDOOR IN EVA-TH sensor error
C122, C123 Dust sensor error
C140 INDOOR Humidity error
C142 Motion sensor error
C143 Fan error(indoor)
C154 Mixed operation error
C161 Option error
C163 K1 filter feed back error
C187 Drain pump error
C665
ERROR MODE YEL GRN RED DESCRIPTION
- ● ○ ○ Power off /VDD NG
- ○ ● ○ Power on reset (1sec)
- ○ ○ ● Normal operation
- ● ● ● Abnormal communication (Indoor <-> Outdoor)
C464 ○ ● ● IPM over current (O.C) error
C461 ○ ● ○ Comp. strating error
C470 ○ ● ● EEPROM data error (no data)
C466 ● ○ ● DC-Link voltage under / Over error
C484 ● ● ○ PFC over load error
C483 ● ○ ● Over voltage protection error
C221 ● ● ○ OUT-TH (Outdoor temperature) sensor error
C416 ○ ● ● DIS-TH (Discharge temperature) Over error
C251 ○ ○ ● DIS-TH (Discharge temperature) sensor error
C468 ● ○ ○ Current sensor error
C474 ● ● ○ Heatsink sensor error
C485 ○ ● ● Input current sensor error
C465 ● ● ● Comp. V_limit/I_limit error
C500 ● ○ ● Heatsinkover temperature error
C231 ○ ● ● CON-TH (Cond temperature) sensor error
C203 ● ○ ○ Time out Comp. (Inv Micom <->Main Micom)
C458 ○ ● ○ Fan error
C471 ● ● ○ EEPROM data error (Main Micom <-> INV Micom)
C467 ● ○ ● Comp. wire missing error
C440 ○ ● ○ Prohibit operation condition error (Heating)
C441 ● ○ ● Prohibit operation condition error (Cooling)
C469 ● ● ○ DC-Link voltage sensor
C488 ○ ○ ● AC Input voltage sensor
C462 ● ○ ○ AC Input I_limit trip error
C554 ○ ● ● Gas leak error
C574 ● ○ ● Gas shortage error
C422 ● ● ○ EEV or valve close error-self diagnosis
- ○ ○ ○ Test operation at Cooling mode
- ● ● ● Test operation at Heating mode
ERROR MODE TYPE DESCRIPTION
7-SEG INDOOR/ OUTDOOR Communication error
C101, C102 Set address error
C108 Room TH sensor error
C121 INDOOR MID, INDOOR IN EVA-TH sensor error
C122, C123 Dust sensor error
C140 INDOOR Humidity error
C142 Motion sensor error
C143 Fan error(indoor)
C154 Mixed operation error
C161 Option error
C163 K1 filter feed back error
C187 Drain pump error
C665
