Manual for Action Camera 230
Uploaded: Aug. 10, 2025, 12:32 a.m.
Getting Started:
Power On/Off: Press and hold the POWER button for several seconds. The Rollei logo will appear, and three red LEDs will glow. The camera defaults to video mode.
Video Recording:
Press the SHOOT button to start recording. Red lights will flash during recording. Press SHOOT again to stop.
Picture Mode:
To enter Picture Mode, turn the camera on and press and hold the SHOOT button for 3 seconds. You'll see a 'P' icon on the screen. Press SHOOT to take a snapshot.
Playback Mode:
Enter Picture mode, then press and hold SHOOT for 3 seconds. Navigate with Wi-Fi, select with SHOOT, and go back with POWER. Select VIDEO or IMAGE to view recordings.
Connecting to TV:
Use a Mini HDMI to HDMI cable. Connect the camera and TV, then select the correct source on the TV.
Wi-Fi Setup:
Download the 'Rollei 400/410' app. Activate Wi-Fi on the camera. Connect your phone to 'Wi-Fi_CAM_000' using password '1234567890'. Open the app for control and preview.
Troubleshooting and error codes
| Q. Why are the red LEDs flickering? | A. The battery is running low. You must recharge the camera. |
|---|---|
| My Rollei Actioncam 230 will NOT turn on. Why? | The battery is flat. You need to recharge it (full recharge from flat will take about 5 hours). |
| My Rollei Actioncam 230 turns off automatically. Why? | The battery is running flat or you set auto power off function. |
| Videos and pictures are blurred. Why? | The lens may be dirty. Clean the lens first. |
| My Rollei Actioncam 230 cannot be seen by my computer. Why? | Try a different USB cable or different USB port. |
