Warranty Information
Refer to the warranty card for details on the warranty.
Basic Operation Summary
Powering On/Off:
- Press the STANDBY/ON switch or button to turn the unit on or put it in standby mode.
- Direct power-on is available by pressing buttons like TUNER, CD, TAPE, MD, or LINE 1, 2, OPT IN (depending on the component and unit).
Tuner Operations:
- Press the TUNER button to select FM or AM band.
- Use the 44 or ►► buttons for manual tuning.
- Press and hold 44 or ►► for high-speed manual tuning.
- Auto tuning can be performed by pressing and holding 44 or ►► until the frequency starts to change.
- Stations can be memorized using the STATION MEMORY button.
- RDS (Radio Data System) features allow display of station name, program type, and radio text.
CD/MD/Cassette Operations:
- Press the CD, MD, or TAPE button to select the respective source.
- Use the Play/Pause (/II), Stop (■), Track Search (◄◄►►), Fast Forward/Reverse (44►►), and Music Search (►►) buttons for playback control.
- Programmed playback, random playback, and repeat playback are available.
- MD editing functions include naming tracks/discs, combining/dividing tracks, moving tracks, and erasing tracks.
Sound Control:
- Adjust bass and treble using the BASS and TREBLE buttons.
- Balance can be adjusted using the BALANCE button.
- Stereo Wide effect can be activated/deactivated using the ST. WIDE button.
Timer Functions:
- Wake-up timer allows the system to turn on and play a source at a set time.
- Timer Recording allows for unattended recording from the tuner or LINE inputs.
- Sleep timer automatically turns the unit off after a specified period.
Troubleshooting and error codes
| Symptom | Likely Cause | Remedy |
|---|---|---|
| No sound | Power plug is disconnected. | Connect the power plug correctly. |
| Not all connection cables are connected prop-erly. | Refer to the section on connections and make sure all connections are correct and secure. | |
| Input selector is not set correctly. | Select the desired component. | |
| Can't switch between func-tions. | Cassette deck or MD recorder is currently recording. | Function selector cannot be operated during recording. |
| Play doesn't start when the play/pause button is pressed. | Disc has been inserted upside down. | Load discs with label side (printed surface)upwards. |
| Can't listen to broadcasts, or sound is distorted. | Disc is dirty. | Clean the disc. |
| Disc has scratches. | Replace the disc. | |
| Input selector is not set to CD | Press the CD function button. | |
| Can't listen to broadcasts, or sound is distorted. | Antenna isn't connected. | Connect the antenna properly. |
| Antenna direction or position is poor. | Orient antenna to the proper direction andposition. | |
| An electrical appliance (fluorescent lamp, hair dryer, etc.) is being used in the near vicinity. | Discontinue use of the appliance producingthe noise, or move it farther away from theantenna. | |
| The frequency interval is incorrectly set. | Change the frequency step ( P. 18). | |
| Monaural indicator is lit in the display. | Press the MONO button so that the "MONO"indicator disappears. (P P. 18). | |
| Broadcast is in stereo, but sound from speakers is monaural. | Monaural indicator is lit in the display. | Press the MONO button so that the "MONO"indicator disappears. (P P. 18). |
| Cassette tray doesn't open. | Electric power cord has been disconnectedduring tape travel. | Reconnect the power cord. |
| Can't record | Erasure-prevention tabs are broken out from the tape cassette. | Either replace the tape, or place cellophane tape over the erasure-prevention tabs (P. 13). |
| Heads are dirty. | Clean the heads ( P. 13). | |
| Sound is muddy or distorted. | The Dolby NR setting is not the same as that used during recording. | Set the Dolby NR system to the same settingas that used during recording ( P. 30). |
| When recording over a previouslyrecorded tape, the previousrecording can still be heard. | Heads are dirty. | |
| Playback sound is muddy or distorted; high frequency sounds are excessively empha-sized. | The Dolby NR setting is not the same as that used during recording. | |
| Sounds recorded from LINE 1 are distorted. | LINE 1 input level is too high. | Set LINE 1 input level to ATT ON ( P. 32). |
| Sounds recorded from LINE 1 are too faint. | LINE 1 input level is set to ATT ON. | Set LINE 1 input level to ATT OFF ( P. 32). |
