BASIC OPERATION

To play a compact disc

  1. Turn on the power to the player.
  2. Insert a magazine, pushing it in until a click sound is heard. (The first disc is automatically set for playback. Inserting a magazine automatically turns on the power when the power is turned off.)
  3. Start playback.

To pause playback temporarily:

Press PAUSE. Playback is paused. Pressing PAUSE again or PLAY resumes from where it was paused.

To stop playback:

Press STOP/CLEAR. The player returns to the beginning of the first track. Pressing STOP/CLEAR twice returns to the beginning of the first track on the first disc and enters stop mode.

To stop playback and take out the magazine:

Press EJECT, remove the magazine, and then press POWER to turn off the power.

Troubleshooting and error codes

Symptom Cause Remedy
Magazine is not expelled when EJECT button is pressed. Power plug is disconnected from outlet.
The POWER switch is STANDBY.
Connect plug to amplifier or wall outlet.
Press the POWER switch ON.
When playback is started, it stops immediately. Pauses or stops during playback. Disc is loaded upside down.
Smudged on the disc, etc.
Load the disc correctly with the label side DOWN.
Clean the smudges from the disc and then play it again.
No sound Output cords are connected incorrectly or loosely.
Incorrect operation of stereo amplifier.
Pin plugs and/or amplifier terminals are dirty.
Player is in pause mode.
Connect properly.
Check the settings of amplifier switches and sound volume controls.
Clean away dirt.
Press the PLAY button.
Sound is distorted, noise is output. Incorrect connections.
Pin plugs and/or amplifier terminals are dirty.
Interference is being picked up from a TV set.
Connect to amplifier's AUX or CD terminals. Do not connect to PHONO terminals.
Clean away dirt.
Switch OFF TV set, or move player away from TV set.
With certain discs, loud noise is produced, or play stops. Disc has bad scratch or warp.
Disc is extremely dirty.
Replace the disc.
Clean disc.
Remote control will not function. (PD-M435 only) Dead batteries.
Too far from player or wrong angle.
Obstruction between player and remote control unit.
Replace batteries.
The distance between remote control unit and player should be no more than about 7 meters.
The operational angle against the front panel is within 30° from right or left end of player.
Relocate remote control unit or remove obstruction.
