Quick Guide to Your Philips Car Audio System
Getting Started
- Installation: Follow the step-by-step wiring instructions to connect the main unit, speakers, and other components. Ensure all connections are secure and insulated.
- Powering On: Press the power button to turn on the unit. Select your preferred language from the displayed options.
- Date & Time Setup: Navigate to the main menu and adjust the date and time settings as needed.
Core Functions
- Navigation: Access the navigation system by pressing the 'NAVI' button. Insert the map card and follow on-screen prompts.
- Radio: Tune to radio stations manually or automatically. Store your favorite stations for quick access. Explore radio range options for optimal reception.
- Media Playback: Load discs (DVD, CD) or connect USB/SD/MMC devices to play audio, video, and image files. Use playback controls for play, pause, and navigation.
Advanced Features
- Bluetooth: Pair your phone to make/receive calls and stream music. Adjust Bluetooth settings for auto-connect and answer preferences.
- Audio/Video Settings: Customize sound settings, including volume, equalizer, and subwoofer options. Adjust video settings like aspect ratio and input.
- System Settings: Modify general settings, language preferences, and DVD rating.
Troubleshooting
- Refer to the troubleshooting section for common issues like no power, no sound, or connection problems.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| No power | Car engine has not been started. | Start the car engine. |
| Connections are incorrect. | Check connections. | |
| Fuse has been damaged. | Replace fuse (see 'Replace fuse' on page 36). | |
| No sound | Volume is too low. | Adjust volume. |
| Speaker connections is incorrect. | Check speaker connections. | |
| No response to the remote control | Obstacles between remote and unit. | Ensure clear path. Point remote directly at unit. |
| Incorrect F/R position. | Switch F/R to correct position. | |
| Function does not work. | Refer to instructions. | |
| Remote control battery depleted. | Replace the remote control battery. | |
| Disc does not play | Disc is upside down. | Ensure printed side is upwards. |
| Disc is dirty. | Clean the disc with a clean, soft, lint-free cloth. | |
| Disc is defective. | Try another disc. | |
| Incompatible disc used. | Try another disc. | |
| Disc rating exceeds the restrict setting. | Change the rating settings to lower one. | |
| Disc region code is not compatible. | Use disc with proper region code. | |
| No image | Parking brake wire connection incorrect. | Check the parking wiring. |
| Image flashes or distorted | Video DVD settings do not match DVD. | Adjust video DVD settings. |
| Video connection improper. | Check the connections. | |
| Noise in broadcasts. | Signals are too weak. | Select other stations with stronger signals. |
| Car antenna connection issue. | Check the connection of the car antenna. | |
| Broadcast setting. | Change broadcast from stereo to mono. | |
| Preset stations lost. | Battery cable not correctly connected. | Connect the battery cable to the terminal that is always live. |
| Fuse is broken | Incorrect fuse type. | Replace it with a 15A fuse. |
| Speaker wire or power wire is grounded. | Check the connections. | |
| Display shows ERR-12 | USB/SD/MMC data error. | Check the USB device or SD/MMC card. |
| About Bluetooth device | ||
| Music playback unavailable | Device cannot be used for music playback. | The device cannot be used with the system to play music. |
| Poor audio quality | Bluetooth reception is poor. | Move device closer or remove obstacles. |
| Cannot connect | Device does not support required profiles. | The device does not support the profiles required for the system. |
| Bluetooth function of device not enabled. | Refer to device's user manual to enable function. | |
| System not in pairing mode. | Ensure system is in pairing mode. | |
| System already connected to another device. | Disconnect other device. | |
| Paired mobile phone connects/disconnects constantly | Bluetooth reception is poor. | Move mobile phone closer or remove obstacles. |
| Phone makes/ends calls. | This does not indicate a system malfunction. | |
| Bluetooth connection deactivated by power-saving feature. | This does not indicate a system malfunction. | |
