Brand: PHILIPS
Category: Audio
Document Type: Parts/Service
Language: EN
Parts/Service for HDD6320/00/05 HDD6330/17
Uploaded: Nov. 21, 2025, 6:26 p.m.
Manual Publish Date: 2005-08-04
Powering On/Off: Slide and hold the ON/OFF/Hold slider down for about 3 seconds to power on/off. Slide up to lock/unlock touch controls.
Playback Controls: Use the Play/Pause key for playback and stopping radio. Use the Rewind/Previous and Forward/Next keys to navigate tracks and fast rewind/forward.
Volume Control: Use the Volume up/down bar.
Menu Navigation: Use the Menu key to access the menu list, Left/Back key to return to previous options, and Right/Select key to select options or move to the next option. Vertical touch strip allows scrolling through lists.
Troubleshooting and error codes
| SYMPTOM | PROCEDURE | TEST IF OK? | NEXT STEP |
|---|---|---|---|
| NO POWER | Connect AC adaptor, charge battery for 15mins. | Yes | No defect, return to customer. |
| Check power cable and AC adaptor. | No | Replace cable/adaptor. | |
| Check power on/off button. | No | Replace connector and switch button. | |
| Replace battery and charge for 15mins. | Yes | No defect, return to customer. | |
| No | Replace mainboard. | ||
| JUKEBOX FREEZES / HANGS UP | Reset by pressing power on/off and volume + keys. | Yes | No defect, return to customer. |
| Open unit, unplug and reconnect battery connector. | Yes | No defect, return to customer. | |
| No | Replace mainboard. | ||
| No | Replace hard disk. | ||
| ERROR MESSAGE SCROLLS ON DISPLAY | Follow repairing procedure with Device Manager. | No | No defect, return to customer. |
| Yes | Replace hard disk. | ||
| NO SOUND | Replace headphone. | No | No defect, return to customer. |
| Yes | Replace mainboard. |
