Manual for K-1

Manual for K-1

Brand: PENTAX

Category: Digital Camera

Document Type:

Language: EN

Uploaded: Aug. 9, 2025, 11:57 p.m.

Warranty Information

Cameras are guaranteed against defects for twelve months from the date of purchase, excluding damage from impact, sand, or mishandling.

Shooting with the Viewfinder:

  1. Remove the front lens cap.
  2. Turn the camera on.
  3. Turn the capture mode selector switch to 'A' (still picture).
  4. Set the focus mode switch to AF.
  5. Set the mode dial to AUTO while pressing the mode dial lock button.
  6. Look through the viewfinder to view the subject.
  7. Position the subject inside the AF frame and press SHUTTER halfway.
  8. Press SHUTTER fully to capture the image.

Shooting with Live View:

  1. Press K to display the Live View image.
  2. Position the subject inside the AF frame on the monitor and press SHUTTER halfway.
  3. Press SHUTTER fully to capture the image.

Refer to the manual for detailed operations like changing settings and playback.

Troubleshooting and error codes

Problem Cause Remedy
The camera does not turn on. The battery is not installed properly. Check the orientation of the battery.
The battery power is low. Charge the battery.
The shutter cannot be released. There is no available space on the memory card. Insert a memory card with available space or delete unwanted images.
Data is being processed. Wait until processing is finished.
The lens aperture ring is set to a position other than 'A'. Set the lens aperture ring to the 'A' position or select [Enable] in [26 Using Aperture Ring].
Autofocus does not work. The autofocus mode is set to AF.S and the subject is not in focus. Set the focus method to MF and adjust focus manually.
The subject is difficult to focus on. Lock focus on another object located at the same distance as your subject, then aim at the target and take a picture. Alternatively, use MF.
The subject is too close. Move away from the subject and take a picture.
The flash does not discharge. The flash mode is set to AUTO or Flash On. When the flash mode is set to AUTO or Flash On, the flash does not discharge if the subject is bright. Change the flash mode.
The camera is not recognized when it is connected to a computer. The USB connection mode is set to [PTP]. Set [USB Connection] to [MSC] in the D2 menu.
Dust or dirt particles appear in images. The CMOS sensor is dirty or dusty. Activate [Dust Removal] from the D4 menu. Refer to “Sensor Cleaning” if the problem persists.
Pixel defects such as bright spots and dark spots appear in the image. There are defective pixels in the CMOS sensor. Activate [Pixel Mapping] from the D4 menu.
