Warranty Information

3-year warranty from date of purchase covering material or manufacturing defects, excluding normal wear and tear.

Operation

  • Changing the battery: Switch off LED light, remove cover screws, replace batteries (LR41), observe polarity, close compartment.
  • Changing/inserting tool/mandrel/collet chuck: Press spindle lock, loosen tensioning nut, remove old tool, insert new tool/mandrel through tensioning nut, place in collet chuck, tighten tensioning nut.
  • Using accessory tool with mandrel: Use screwdriver side of combination key to loosen/tighten screw, insert mandrel, insert accessory tool between washers, tighten screw.
  • Switching on/off/setting speed range: Connect plug to mains adapter, connect adapter to power source, push on/off switch to desired speed (5000-20000 RPM) or OFF.
  • Using grip ring with LED light: Switch off product, press spindle lock, unscrew tensioning nut and grip ring, screw on new grip ring with LED light, re-tighten tensioning nut, switch on LED light.
  • Processing materials: Use milling bits for steel/iron at max speed, test speeds for other metals, use low speeds for plastics, high speeds for wood, medium for cleaning/polishing.
