Operation Summary

Shooting and Recording: Ensure proper inspections before shooting. Attach a fully charged battery, turn on the power, and load a cassette. Set switches for GAIN, OUTPUT, AUDIO SELECT, and TCG as needed. Point the camera, adjust focus and zoom, set shutter speed if necessary, and press VTR START to begin recording. Press again to stop.
Scene-to-Scene Continuity: Maintain continuity by pressing VTR START in rec-pause mode. If the unit was turned off, switch power back on and press VTR START. To ensure continuity at other times, play back the tape, stop at the desired point, press the RET button, then press VTR START.
NEWS REC function (SDC615): This function aids in news gathering by controlling the VTR START button acknowledgment time to allow continuous recording, preventing missed shots.

Item/ Data storage	Variable range	Remarks
CORRECT	ON	For selecting ON or OFF for the digital black shading compensation.
CORRECT	OFF	For executing the digital black shading compensation.
DETECTION (DIG)	–	For executing the digital black shading compensation.
DETECTION (DIG)	–	CORRECT	ON CUFE OFF	For selecting ON or OFF for the white shading compensation.
DETECTION (V SAW)	–	CORRECT	ON CUFE OFF	For executing the white shading compensation.
DETECTION (V SAW)	–	HUMID OPE	ON OFF	For selecting whether or not to continue operation when HUMID alarm state has occurred.
REC START	ALL NORMAL				For selecting how recording start is to be accepted.
						PAUSE TIMER	10min 20min 30min 60min	For selecting the time during which REC/ PAUSE is to continue.
									ECU REC CHK SW	R.REVIEW RETAKE	For setting the unit's operation to be performed using the REC check button on the ECU. R.REVIEW: The rec-review operation is performed. RETAKE: The retake operation is performed, after which playback is initiated automatically.
