Manual for X461UN

Basic Operation

Power ON and OFF Modes

The LCD monitor power indicator will turn green while powered on and will turn red or amber while powered off.

NOTE: The Main Power Switch must be in the ON position in order to power up the monitor using the remote control or the Power Button on the front of the LCD.

Using Power Management

The LCD monitor follows the VESA approved DPM Power Management function. This function automatically reduces power consumption when the display is not in use.

Selecting a video source

Use the input button to set the desired video source.

Picture Aspect

Select the desired picture aspect ratio from options like FULL, NORMAL, WIDE, and ZOOM.

Information OSD

Press the DISPLAY button on the remote to view information such as Monitor ID, Input Source, and Picture Size.

Picture Mode

Select from various picture modes like HIGHBRIGHT, STANDARD, sRGB, CINEMA, AMBIENT1, and AMBIENT2 to optimize image quality.

AMBIENT Mode

The monitor automatically adjusts brightness based on ambient light. AUTO BRIGHTNESS is disabled when AMBIENT1 or AMBIENT2 is selected.

OSD (On-Screen-Display) Controls

Use the remote control or the control panel buttons to navigate menus and adjust settings.

PICTURE Menu

Adjust settings like BRIGHTNESS, CONTRAST, SHARPNESS, BLACK LEVEL, TINT, COLOR, COLOR TEMPERATURE, COLOR CONTROL, GAMMA SELECTION, MOVIE SETTINGS, PICTURE MODE, and PICTURE RESET.

ADJUST Menu

Access settings like AUTO SETUP, AUTO ADJUST, H POSITION, V POSITION, CLOCK, CLOCK PHASE, and Gain/Offset.

TERMINAL SETTING

Configure settings for DVI MODE, BNC MODE, SCART MODE, HDMI SIGNAL, SCAN CONVERSION, COLOR SYSTEM, and SCAN MODE.

ADVANCED OPTION

Options include ADVANCED OPTION RESET and FACTORY RESET.
