Manual for Versa UltraLite/DayLite

Manual for Versa UltraLite/DayLite

Brand: NEC

Category: Laptop

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:12 p.m.

Manual Publish Date: 2001-08-01

Warranty Information

The manual discusses proprietary notice and liability disclaimers, with product warranties covered by a separate Warranty Statement.

  • The notebook can be powered by an AC adapter, primary and secondary batteries, or an optional Auto adapter.
  • The AC adapter connects to a wall outlet to run the notebook or recharge batteries.
  • Power on the system by sliding the latch, raising the LCD panel, and then sliding the Power button forward.
  • The notebook has a primary and a secondary battery; the primary is built-in and non-replaceable, while the secondary is removable.
  • Tips for extending battery life include changing display color depth, using the LongRun utility, keeping the notebook charged, adjusting brightness, and disabling the IR port if not in use.
  • Battery status can be determined by hovering over or clicking the power icon on the taskbar, or through Power Management settings in the Control Panel.

Troubleshooting and error codes

Startup Problems
Problem Possible Cause/Solution
No power when Power button is pressed
  • AC adapter not connected properly or not plugged in.
  • Primary battery depleted. Connect AC adapter to recharge.
  • Secondary battery not installed or depleted. Install and/or recharge.
System does not power on after pressing Power button, but LEDs light up
  • BIOS requires updated configuration. Check DIP switch settings.
  • Hard drive not detected. Check hard drive installation.
System powers on but LCD panel remains blank
  • LCD panel not enabled in BIOS setup.
  • LCD panel disconnected or faulty.
POST Error Messages
Message Possible Cause/Solution
Memory error
  • Memory module is not installed correctly. Reseat the memory module.
  • Faulty memory module. Replace memory module.
Hard disk error
  • Hard disk not detected. Check hard disk installation.
  • Faulty hard disk. Replace hard disk.
CMOS checksum error
  • CMOS battery depleted. Replace CMOS battery.
  • BIOS configuration error. Run BIOS setup to reconfigure.
