Manual for PPC/PMC-8260/DS1

Name: Manual for PPC/PMC-8260/DS1
Brand: Motorola
Availability: InStock

Brand: Motorola

Category: Computer Hardware

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:48 p.m.

Manual Publish Date: 2006-07-01

Warranty Information

No specific warranty period is mentioned in the provided sections of the manual.

This manual provides detailed information on the PPC/PMC-8260/DS1, including its features, installation procedures, indicators, connectors, firmware, memory map, device descriptions, and TDM channel configuration. It also includes sections on synchronizing clocks, troubleshooting, and conventions used throughout the document. The guide is intended for users with a background in electronics and telecommunications, covering topics from basic setup to advanced configurations.

Troubleshooting and error codes

Problem	Possible Reason	Solution
During Power Up	Primary Booter does not start	The ROM image area in the boot flash device is not empty (LEDs switch to green/off after POST). Enforce primary booter execution via PCR register (see "Controlling Boot Process" page 4-13).
During Power Up	Application in ROM image area does not start / LEDs switch to yellow/yellow after green/off.	A software reset occurred while executing the ROM image. Configure ROM image so that firmware disables the watchdog before executing it (see "SYPCR Register" page 4-9). Add software watchdog support to application in ROM image area.
After Power Up	LEDs remain yellow/yellow after power-up	Wrong switch settings. Verify switch settings (all switches must be in OFF position).
During Operation	PCI error when trying to communicate with the firmware via the 4 MByte PCI window	The address translation of the PCI window is not enabled. Allow firmware to enable address translation by setting bit 3 (value 816) in mailbox register 6 (offset 46816) of PowerSpan. This can be done either before resetting the module or while the primary booter is running. Enable address translation by setting bits 31 and 30 (hex. value C000000016) in target image 1 control register (offset 10016) of PowerSpan.
