Manual for MVME197DP and MVME197SP

Chapter 1: General Information provides an introduction, description, features, specifications, cooling requirements, FCC compliance, equipment requirements, and support information for the MVME197DP/SP series. Chapter 2: Hardware Preparation and Installation covers unpacking, hardware preparation, switch configurations, connectors, and installation instructions for the MVME197DP/SP modules and MVME712X transition modules. Chapter 3: Operating Instructions details controls, indicators, ABORT and RESET switches, front panel LEDs, and memory maps, including processor bus and local device memory maps. Chapter 4: Functional Description outlines the functional aspects of the MVME197DP/SP, including the MC88110 MPU, cache controller, memory (DRAM, Flash, BOOT ROM, SRAM), VMEbus interface, I/O interfaces (Serial, Printer, Ethernet, SCSI), and peripheral resources. Appendix A: EIA-232-D Interconnections provides detailed information on EIA-232-D connections. The List of Figures and List of Tables provide quick references to visual and tabular data within the manual.
