The manual outlines the specifications, wiring diagrams, dimensions, refrigerant circuit, troubleshooting, parts, and disassembly instructions for Mitsubishi Home Refrigerators, models MR-E55R-F-C, MR-E55R-PS-C, MR-E60R-F-C, and MR-E60R-PS-C. It details various functions like temperature control, ice making, supercool freezing, and eco mode. Key sections include troubleshooting flowcharts, error code displays, and specific test modes like compressor speed check and thermistor temperature check. The document also provides step-by-step instructions for disassembly and reassembly of various components, including interior lights, control panels, fan motors, and the evaporator. Safety precautions and assembly cautions are emphasized throughout.

Troubleshooting and error codes

Item	Operation method	Display or self-check operation	Display period	Others
① Ice making test operation.	Press the 製氷切替 switch. All items except (*6) listed up on the table at page 25 will be checked. ("Beep" is heard)	1.Conduct the automatic ice making test. (The display of ice making compartment setting blinks) 2.When trouble is found, all error codes are displayed. 3.When error is not found, nothing is displayed.	For 10 minutes after setting.	Self-check is not available during child lock, cooking timer, changing the rotational speed of compressor, checking the temperature of thermistor, damper ope- ration and demonstration modes.
② Power input.	Plug the power cord into outlet. All items except (*6) listed up on the table at page 25 will be checked.	1.When trouble is found, all troubles except E50 ~ E55 are displayed. 2.When error is not found, nothing is displayed.	For 10 minutes after power is supplied.	Self-check is not available during demonstration mode.
③ Error history	Refer to 5-1.(6)5) Error history display mode.	1.When trouble is found, all troubles except E50 ~ E57 are displayed. 2.When error is not found, nothing is displayed.	For 1 hour after setting, or until mode is released.	Self-check is not available during child lock, cooking timer, changing the rotational speed of compressor, checking the temperature of thermistor, damper ope- ration and demonstration modes.
