Manual for VS-60HS12U
Uploaded: Nov. 21, 2025, 6:45 p.m.
Manual Publish Date: 2014-12-22
Basic Operation:
- The cubes can be operated with the remote control unit or control software "Wallaby".
- Remote Control Unit: Face the remote control toward the screen on each cube to control. Alternatively, facing the MASTER cube directs other cubes. The wired remote control can be connected directly to the imaging monitors.
- Operation Modes: Monitors have "normal mode" (usual operation) and "advanced mode" (set-up and adjustment). The [NORMAL] button switches between modes when no adjustment menu is displayed.
- Advanced Mode Status Bar: Displays information like selected display memory, input memory, input signal, unit ID, and adjustment status.
- Menus: Accessed via the [MENU1] button in advanced mode. Use arrow keys to navigate and [ENTER] to select/confirm. The [MENU1] button can switch to a simple menu display.
- Adjusts Mitsubishi display walls via RS-232C or network.
- Supports up to 998 monitors.
- Requires installation and connection via RS-232C or network.
- Allows unit ID and IP address assignment.
