Brand: Miele
Category: Vacuum Cleaner
Document Type: Manual
Language: EN
Manual for HS19
Uploaded: Nov. 21, 2025, 7:17 p.m.
Warranty Information
The warranty is valid for 2 years from the date of purchase.
Assembling the Vacuum Cleaner
Assemble the vacuum cleaner in two different ways by connecting the suction tube above or below the PowerUnit.
Connecting Components
Connect the Comfort handle to the suction tube or PowerUnit. Connect the PowerUnit and suction tube. Insert the battery into the PowerUnit. Connect the Electrobrush to the PowerUnit or suction tube connector.
Charging the Battery
Charge the battery directly or using the wall mounting. The battery charging state indicator shows the charging progress.
Using the Vacuum Cleaner
Switch on/off and regulate suction power using the Comfort handle. Utilize the self-standing function for short pauses.
Maintenance
Empty the dust container, clean filters, and clean the Electrobrush/handheld brush as needed.
Troubleshooting and error codes
| Problem | Cause and remedy |
|---|---|
| Bottom light flashes quickly | Internal system error: Remove the battery, wait for 10 seconds, reinsert it and charge it. |
| Bottom and middle lights flash quickly | "Battery overheating" error: Wait for approximately 30 minutes before switching the vacuum cleaner back on again. |
| Middle and top lights flash quickly | "Battery not recognised" error: Insert an original Miele AP01 lithium-ion rechargeable battery (HX LA). |
| Top light flashes quickly | "Comfort handle not recognised" error: Remove the Comfort handle and reconnect it. Remove the battery, wait for 10 seconds and reinsert it. |
| The cleaning performance is poor. | The dust container is full. Empty and clean the dust container. The Electrobrush is dirty/blocked. Clean the roller brush and the inside of the Electrobrush. |
| Cleaning performance is reduced. | The fine dust filter is dirty. Clean the fine dust filter. The pre-filter is dirty. Clean the pre-filter. |
| The Electrobrush switches itself off. | The Electrobrush is overloaded – this can happen on surfaces like deep-pile carpet. Switch the vacuum cleaner off and switch it on again at a reduced suction power level. |
| The operating noise is changing during vacuuming. | The floor covering detection function is activated. The Electrobrush power output is automatically set to the optimum level. The noise is not unusual. |
| The vacuum cleaner does not start when it is switched on. | There is no battery inserted or the battery is inserted incorrectly. Insert the battery or check its position. The rechargeable battery is not sufficiently charged. Charge the battery. An original Miele battery has not been inserted. Insert an original Miele AP01 lithium-ion rechargeable battery. The charger is still plugged in. Pull the plug out of the charging socket. |
