Manual for H 5030 BM, H 5040 BM
Uploaded: Nov. 21, 2025, 9:21 p.m.
Warranty Information
The warranty for this appliance is 2 years. Refer to your warranty booklet for details.
Microwave Function: Cooks, defrosts, and reheats food quickly. Heat is produced directly in the food, retaining nutrients and preserving taste, color, and texture. Power levels range from 80W to 1000W.
Functions without Microwave:
- Fan Plus: Circulates heated air for even cooking on up to two levels simultaneously.
- Grill: For grilling thin cuts and browning dishes.
- Defrost: Gently defrosts frozen food at room temperature with fan circulation.
- Fan Grill: Grills thicker cuts at lower temperatures than the standard Grill function.
- Rapid Heat-up: Quickly heats the appliance to the required temperature.
Combination Programmes: Combine microwave power with traditional functions for quick cooking and even browning. Examples include Microwave+Grill, Microwave+Fan Plus, and Microwave+Fan Grill.
Other Functions: Automatic switch-off, Delay start, and Minute minder (egg timer).
Troubleshooting and error codes
| Problem | Possible cause and remedy |
|---|---|
| The display is dark. | Check whether the time display is set so that it does not appear in the display (see "Settings – P I"). Check that the appliance is plugged into the mains supply and switched on at the socket. Check whether the mains fuse has tripped. If it has, contact a qualified electrician or Miele. |
| A programme will not start. | Check that, if using a programme with microwave, the door is shut properly. Check that a power level and duration have been entered if operating in microwave mode. Check that, if operating with a combination programme, the following have been entered: a power level, a duration for the microwave mode and a temperature for the conventional oven operating mode. |
| If the door is opened whilst the oven is operating on microwave solo, the oven will stop making a noise. | This is because the cooling fan switches off when the door is opened. It does not indicate a fault. |
| A noise is heard after a programme has finished. | The cooling fan continues to run for a while after the oven has been switched off to prevent any humidity building up in the oven, on the control panel or on the oven housing unit. When the temperature has fallen sufficiently, the fan switches off automatically. |
| An abnormal sound can be heard when the oven is operating in microwave mode. | Check if there are sparks caused by using metal dishes (see "Suitable containers for microwave ovens"). Check if the food is covered with aluminium foil. Remove the foil. Check if the rack is inside the oven. Always use the glass tray when using the oven in Microwave solo mode. |
| The microwave works and the oven heats up, but the interior lighting does not come on. | Check if the halogen lamp is defective. If so, it needs to be replaced as follows. Disconnect the appliance from the electricity supply (switch off and unplug at the socket, or remove the fuse, or switch off at the isolator as appropriate). The lamp cover consists of two parts: a glass piece and a mounting. Hold the lamp cover securely when removing it so that it doesn't fall. Place a tea towel over the floor of the oven and the open door to protect them. Remove the screw to the lamp cover using a T20 torx screwdriver, and take off the cover. Pull the halogen lamp out. Replace the halogen lamp. Specification: 12 V, 10 W, heat resistant to 300 °C, fitting G4, Osram, type 64418. Do not touch the halogen lamp with bare fingers. Please follow the manufacturer's instructions. Replace the glass piece in the mounting, and refit the lamp cover. Make sure that the lug on the mounting is correctly located in the notch in the roof of the oven, then screw the mounting back into place. Reconnect the appliance to the mains supply. |
| Fault messages in the display | Fault messages are indicated by "Fault" plus a number. Call Miele. |
