Starting the Engine:

  • Ensure spark plug wire is connected and boot is secure.
  • Set throttle choke lever to "START" position.
  • Grasp brake control handle and pull starter handle rapidly.
  • Return starter handle slowly after engine starts.
  • Release brake control handle to stop engine and blade.

Operation:

  • Hold brake control handle firmly with both hands.
  • Release handle to stop engine and blade.
  • For self-drive models (PLM5121N2), engage self-drive control handle to move forward. Release to stop.

Stopping the Engine:

  • Release brake control handle.
  • Disconnect and ground spark plug wire.

Mulching:

  • Cut grass in one step, finely chopped and returned as fertilizer.
  • Hints: regular cut-back, sharp blade, do not mow wet grass, set max engine speed, clean mulching wedge.

Side Discharge:

  • Lift sideward flap, mount discharge channel, lower flap.

Troubleshooting and error codes

PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
Engine does not start. Throttle chock not in the correct position for the prevailing conditions. Move throttle chock to correct position.
Fuel tank is empty. Fill tank with fuel: refer to ENGINE OWNER'S MANUAL.
Air cleaner element is dirty. Clean air cleaner element: refer to ENGINE OWNER'S MANUAL.
Spark plug loose. Tighten spark plug to 25-30 Nm.
Spark plug wire loose or disconnected from plug. Install spark plug wire on spark plug.
Spark plug gap is incorrect. Set gap between electrodes at 0.7 to 0.8 mm.
Spark plug is defective. Install new, correctly gapped plug: refer to ENGINE OWNER'S MANUAL.
Carburetor is flooded with fuel. Remove air cleaner element and pull starter rope continuously until carburetor clears itself and install air cleaner element.
Engine difficult to start or loses power. Faulty ignition module. Contact the service agent.
Dirt, water, or stale fuel tank. Drain fuel and clean tank. Fill tank with clean, fresh fuel.
Vent hole in fuel tank cap is plugged. Clean or replace fuel tank cap.
Engine operates erratically. Air cleaner element is dirty. Clean air cleaner element.
Spark plug is defective. Install new, correctly gapped plug: refer to ENGINE OWNER'S MANUAL.
Spark plug gap is incorrect. Set gap between electrodes at 0.7 to 0.8 mm.
Engine idles poorly. Air cleaner element is dirty. Clean air cleaner element: refer to ENGINE OWNER'S MANUAL.
Air cleaner element is dirty. Clean air cleaner element: refer to ENGINE OWNER'S MANUAL.
Engine skips at high speed. Air slots in engine shroud are blocked. Remove debris from slots.
Cooling fins and air passages under engine blower housing are blocked. Remove debris from cooling fins and air passages.
Engine overheats. Gap between electrodes of spark plug is too close. Set gap between electrodes at 0.7 to 0.8 mm.
Cooling air flow is restricted. Remover any debris from slots in shroud, blower housing, air passages.
Mower vibrates abnormally. Incorrect spark plug. Install original spark plug and cooling fins on engine.
Cutting assembly is loose. Tighten blade.
Cutting assembly is unbalanced. Balance blade.
