Parts/Service for LCE3610SB

Brand: LG logo LG

Category: Home Appliance

Document Type: Parts/Service

Language: EN

Uploaded: Nov. 21, 2025, 6:26 p.m.

Manual Publish Date: 2010-05-01

Warranty Information

LG Electronics assumes no responsibility for repairs made by anyone other than Authorized Service Technicians.

This manual provides technicians with information on the operation and service of the LG Ceramic Glass Radiant Cooktop, model LCE3610SB. It covers safety precautions, installation instructions, cookware tips, cleaning and care, component testing, failure mode flow charts, troubleshooting, and replacement parts. The manual emphasizes safety during installation and operation, including proper electrical connections and handling of hot surfaces. It details how to select appropriate cookware, maintain the cooktop's surface, and diagnose common issues. Component testing procedures are outlined with expected resistance values. Troubleshooting guides and exploded views aid in identifying and resolving problems.

Troubleshooting and error codes

Problem	Possible Causes	Solutions
Cooktop does not work	• Cooktop controls are locked. • Circuit breaker has tripped. • Power outage. • Installation wiring not complete.	• See USING CHILD LOCK to turn off the CHILD LOCK feature. • Reset the circuit breakers. • Check house lights to confirm power outage. • See the page 68-69.
Cooktop does not heat	• Incorrect Cooking Zone selected. • No power to cooktop.	• Make sure the correct control is ON for the Cooking Zone being used. • See the page 70-71. • See "Cooktop does not work" above.
Elements turns off while cooking.	• Cooktop inner temperature too High.	• Check that cooktop has been installed According to the installation instructions. • See the page 12-18. • Check the connection of fan assembly.
Elements do not get hot enough.	• Touch controls may not be set properly. • Cookware may not be shape or flat or the correct size.	• Check the power level. • Use the recommended cookware. • See the page 19-20.
A fan sound can be heard.	• Cooktop inner temperature is High.	• This is normal. The cooling fan will run when any element is turned on. With the heavy use the fan may continue to run after the controls are turned off until the cooktop has cooled.
