Brand:
LG
Category: Dishwasher
Document Type: Manual
Language: EN
Manual for D1453W(L,M,T,B,C,D,A)F(B,U) / D1463W(L,M,T,B,C,D,A)F(B,U) / DW-TN600W / DW-TN600T
Uploaded: Nov. 21, 2025, 6:59 p.m.
Warranty Information
The warranty period is 24 months. Refer to the rating label for detailed warranty information.
How to Use and Operate
Before operating, ensure you have checked water hardness and set the softening system level. Load dishes appropriately in the cutlery basket, cutlery rack, upper rack, and lower rack. Ensure spray arms can rotate freely. Measure detergent and select the desired programme. The dishwasher will start automatically after 10 seconds. If the door is opened, the machine stops and resumes when re-closed. At the end of the cycle, "End" is displayed, and the machine may switch off automatically. For optimal drying, partially open the door after the cycle. Refill rinse aid and salt as indicated by indicator lights.
Troubleshooting and error codes
| Problem | Possible Causes | Solution |
|---|---|---|
| No lights come on when the power is turned on. | • Plug is not properly inserted into the socket. • Fuses blown or circuit breaker tripped. • The electricity from the house was cut off. |
• Check the plug. • Check the electricity. • Call for service. |
| The machine does not start. | • Door is not fully closed. • The start button is not pressed. |
• Close the door. • Press the start button. |
| The spray arms do not rotate smoothly. | • The mounting of the spray arms is blocked by food particles. | • Clean the holes of the spray arm. |
| White deposits are left on the dishwasher after washing. | • The amount of detergent or rinse-aid set incorrectly. • The salt container is empty. • The salt container cap is not securely screwed on. |
• Check the detergent or rinse-aid. • Check the salt container or cap. |
| Streaks are left on glassware. | • Too little Rinse-Aid dispensed. | • Fill the rinse-aid. • Adjust the level of rinse-aid container. |
| Dry results are not satisfactory. | • Too little Rinse-Aid dispensed. | • Fill the rinse-aid. • Adjust the level of rinse-aid container. |
| Washing results are not satisfactory. | • Incorrect amount of detergent. • Utensils incorrectly arranged or overloaded. • Filters are clogged. • Water jet holes of spray arms blocked. • Spray arm's rotation obstructed by utensils. • Unsuitable programme selected. |
- |
| The display shows OE code. (Water is not pumped away.) | • The drain hose is kinked. • The filter is clogged. • Motor trouble. (Washing motor or Drain motor) |
• Straighten hose(s). • Clean the filter. • If you can not solve the problem, call for service. |
| The display shows IE code. | • Water is not supplied. • Water tap is not opened. • Water sensor has trouble. |
• Check the water tap. • If you can not solve the problem, call for service. |
| The display shows EI code. (Automatically Drain pump operated.) | • Water is leaking from the hose connections. • Damage to the unit has been caused by a water leak. |
• Close the water tap and unplug the power plug. |
| The display shows FE code. (Automatically Drain pump operated.) | • Excessive water is supplied, which is more than the normal water level. • There is a problem with the inlet valve. |
• Close the water tap and unplug the power plug. |
| The display shows HE code. | • The water heater circuit is damaged. | • Call for service. |
| The display shows tE code. | • Thermistor trouble or very high inlet water temperature. | • Call for service. |
| The display shows LE code. | • Motor trouble. | • Call for service. |
| Code: The display shows PF code | This indicates there was a power failure. This function protects the dishwasher in the event that the power goes out or the power to the unit is disrupted. When power is returned, and a button is pushed, this will display for 10 seconds and then go away. | - |
| Code: The display shows Cd code | Cd means Cool-dry. This is an additional drying cycle to assist drying performance. This cycle runs for a further 60 minutes after the course has finished. It can be interrupted at any time by opening the door. | - |
| Code: The display shows CL code | CL means Child-Lock. This function is used to lock or unlock the control buttons to prevent all the settings from being changed by a child. It can only be activated during the wash cycle. | - |
| Code: The display shows F code | When the unit is displaying F, the sensor is measuring the water clarity. After 5 minutes of sensing (except draining and filling), the unit's display will then show the processing time. | - |
| Code: The display shows numbers between 1 ~ 19 | This is not an error code, but indicates the setting of the delay start. To cancel the function, turn the power off. To change the course and option, open the door and select another course and option. Countdown will then continue after door is closed again. | - |
| Buzzing sound. (High Temperature Alarm) | This is not an error. When you open the door right after heating wash, rinse or dry, buzzing sound would keep on ringing for safety if the inside is heated. | - |
| Odor | If the dishwasher is not used daily, we recommend to run a Quick cycle once or twice a day until you have a full load. In case odor still persists, run a vinegar rinse through a Auto cycle by putting 2cup(500ml) of white vinegar in an upright measuring cup in the lower rack, without detergent. We recommend to maintain according to the USER MAINTENANCE INSTRUCTIONS. | - |
