Manual for KM-V3/V4/V6/V7
Uploaded: April 20, 2026, 8 p.m.
Starting Up the System:
After installation and power application, the ACU screen displays sequences: POWER ON, data communication, satellite search, and finally satellite lock and tracking.
Sleep Mode:
The system enters sleep mode after 8 minutes of no satellite lock and wakes up automatically after 10 minutes or when a new satellite is selected.
Changing Target Satellite:
The antenna is pre-programmed with up to 6 satellites. Users can select a new target satellite from the SATELLITE SELECT menu. The antenna will automatically search and track the selected satellite.
Setup Mode:
Allows configuration of Satellite List, LNB Info, GPS, editing satellite info, and resetting to default settings.
Monitoring and Diagnostics:
Check antenna status including Power, Band (0/22K), GPS, Satellite Signal, and Software Version.
Troubleshooting and error codes
| Error Code | Description |
|---|---|
| E01 | The initialization of Antenna control board failed |
| E02 | Antenna Input Power is tested. If failed, check the RF cable. |
| E03 | Skew System is tested. If Failed, check the control board, skew motor. |
| E04 | Tuner is tested. If failed, check the tuner and cable connection. |
| E05 | LNB is tested. If failed, check the LNB and control board. |
| E06 | Gyro board is tested. If failed, check the gyro board, cable connection. |
| E07 | EL axis is tested. If failed, check the limit sensors, motor and belt for EL axis. |
| E08 | AZ axis is tested. If failed, check the limit sensors, motor and belt for AZ axis. |
