Manual for KSBSDIX16 / KSBS DIB17

Operating Your Fridge Freezer

Temperature Setting: Adjust fridge temperature between 2°C to 8°C and freezer between -14°C to -24°C using the control panel buttons.

Special Modes:

• Super Cool: Press and hold for 3 seconds to rapidly cool the fridge. Illuminates and deactivates automatically after 3 hours or when pressed again.
• Super Freeze: Press and hold for 3 seconds to rapidly freeze the freezer. Illuminates and deactivates automatically after 26 hours or when pressed again.
• Holiday Mode: Press the Holiday button. Illuminates. Ideal for periods away; the ice maker turns off automatically. Do not store food in the fridge.
• Eco Mode: Press the Eco button for energy saving. Illuminates. Sets fridge to 8°C and freezer to -15°C. Deactivates when pressed again.

Door Alarm: Activates if a door is left open for over 2 minutes, sounding 3 times per minute. Deactivates by pressing the Alarm button or closing the door.

Child Lock: Press and hold the Child Lock button for 3 seconds to activate (illuminates). Press and hold again to deactivate (extinguishes).

Dispenser: Press Cubed or Crushed for ice, Water for water. Flush lines with water on first use and discard one day's worth of ice.

Ice Maker: Press Ice Off to stop ice production (illuminates). Press again to resume (extinguishes).
