Brand: KENWOOD
Category: Refrigerator
Document Type: Manual
Language: EN
Manual for KNF60HX17
Uploaded: Nov. 21, 2025, 6:57 p.m.
Warranty Information
None
Switching on your unit: Connect the mains cable. Use the electronic control panel to set the fridge (2-8°C) and freezer (-16 to -22°C) temperatures. Allow 24 hours for the unit to reach the correct temperature before filling with food. For temperature checking, use a special fridge/freezer thermometer.
Mode Button: Press repeatedly to cycle through ECO, Holiday, Super Freeze, and User Defined modes.
ECO Mode: Saves energy. Fridge temperature automatically sets to 5°C, freezer to -18°C.
Holiday Mode: For periods away. Fridge temperature sets to 17°C. Do not store food in the fridge.
Super Freeze Mode: Quickly lowers freezer temperature. Switches off automatically after 26 hours.
Lock/Unlock: Press and hold MODE for 3 seconds to lock/unlock the keypad.
Mode Button: Press repeatedly to cycle through ECO, Holiday, Super Freeze, and User Defined modes.
ECO Mode: Saves energy. Fridge temperature automatically sets to 5°C, freezer to -18°C.
Holiday Mode: For periods away. Fridge temperature sets to 17°C. Do not store food in the fridge.
Super Freeze Mode: Quickly lowers freezer temperature. Switches off automatically after 26 hours.
Lock/Unlock: Press and hold MODE for 3 seconds to lock/unlock the keypad.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Unit does not operate | Unit is not plugged in or is switched off. | Ensure the unit is plugged in and switched on. |
| Compressor is not running | Unit is not plugged in or is switched off. | Ensure the unit is plugged in and switched on. |
| Interior light does not operate | Bulb has blown or the door is not open. | Ensure the door is open. Contact a qualified service agent to change the bulb. |
| Unit is not sufficiently cool | Door is not closed properly or is frequently opened. | Ensure the door is closed properly and limit door openings. |
| Temperature is set incorrectly. | Adjust the temperature settings. | |
| The unit is too close to a heat source. | Move the unit away from heat sources. | |
| Unit is overloaded with food. | Remove some food. | |
| Excessive condensation or frost | Door is not closed properly or is frequently opened. | Ensure the door is closed properly and limit door openings. |
| The seals are dirty. | Clean the door seals. | |
| Unusual noises | Normal operation - circulation of refrigerant. | This is normal and does not affect performance. |
