Manual for RXD-M51/M51MD
Uploaded: Nov. 21, 2025, 6:39 p.m.
1. Initialization
To set initial conditions: Press the [SET] key, then plug in the AC power cord.
To initialize operation: Unplug the power cord, then while holding the "set/demo" key depressed, plug the power cord back in. This resets the microcomputer and returns it to factory settings.
2. Test Modes
Various test modes are available for different sections (CD player, MD player, DECK section). These modes are entered by pressing specific keys while plugging in the AC power cord. Refer to the respective sections (6-4 for CD, 6-3 for MD, 6-2 for DECK) for details on setting, canceling, and operation.
3. Adjustments
Specific adjustments are outlined for the CD player (Page 11) and MD player (Pages 8-10). These include optical pickup adjustments, laser power, focus, and jitter adjustments, requiring specific test discs and equipment.
Troubleshooting and error codes
| 7. MD mechanism error message | |
| DISPLAY | DESCRIPTION |
| BLANK DISC | Non Recorded disc |
| CAN'T COPY | Inhibit to record by SCMS |
| CAN'T EDIT | Inhibit to edit by MD standard |
| CAN'T REC | Inhibit to record by disc damage(10 or more defects/recordable cluster is 0) |
| DISC ERROR** | OR: UTOC read error or FTNO>LTNO (edit/record) permit ALL ERASE only DO: Start address TNO>endless TNO |
| DISC FULL | No recordable area |
| MECH ERR** | 10-13: head poor down 20-23: head poor up No disc in the unit |
| NO TRACKS | Disc recorded title only |
| NOT AUDIO | Disc recorded audio signal. |
| PLAY ONLY | Record disc inhibited to record |
| PROTECTED | In mode of reading TOC or UTOC |
| READING | 30: Search time over in playback, FF or FB 31: Search time over in REC-PAUSE 32: Search time over in record |
| SRCH ERR** | High temperature |
| TEMP OVER | Input over letter of title |
| UNIT ERROR | Hardware damage |
| UTOC W ERR | Error of writing to UTOC |
| WRITING | In writing to UTOC |
