Brand: JVC
Category: Television
Document Type: Manual
Language: EN
Manual for AV-27530
Uploaded: Nov. 21, 2025, 6:13 p.m.
Warranty Information
This limited warranty covers defective materials and workmanship for 1 year for parts and labor, and 2 years for the picture tube.
Basic Operation
Turn the television on and off by pressing the POWER button on the remote control.
Connecting Your Devices
Follow the flow chart to determine the correct connection setup for your devices (Cable TV Box, VCR, DVD player, Satellite TV system). Connect devices using the provided cables (Coaxial, Component, Composite, Audio, S-Video). Plug the power cord into an outlet and turn on the TV.
Auto Tuner Setup
Press the MENU button on the remote, navigate to AUTO TUNER SETUP, and select CABLE or AIR. Press START to begin the auto tuner setup, which will memorize all receivable channels. The setup is complete when "PROGRAMMING OVER !" is displayed.
Onscreen Menus
Use the MENU button to access the onscreen menu system. Navigate using the CH+/- buttons (Up/Down arrows) and VOLUME+/- buttons (Left/Right arrows). The "press button" icon indicates which button to press on the remote.
Troubleshooting and error codes
| PROBLEMS | CHECK |
|---|---|
| There is no power | • See if the power cord became unplugged. • Check for a blown fuse or circuit breaker or a power outage. |
| There is no picture or sound | • The antenna could be disconnected. • The input mode could be set improperly. See page 35. • The tuner (Auto Tuner Setup) could be set improperly. See page 18. • The TV station may be having difficulties. Check to see if other stations are working. |
| Remote control is not operating properly or at all | • Check to see that the batteries are still working and properly installed. Make sure the remote has a clear sight path to the TV. • You may be too far from the TV. You must be within 23 feet (7 meters). |
| You cannot select a certain channel | • Make sure the channels have been programmed. See "Channel Summary", page 18. • Check to see if the channel is locked. See "Channel Summary - Lock" page 19. |
| The power turns off by itself | • Make sure the set did not become unplugged. • Perhaps the On/Off Timer is set. See page 31. • Check to see if the Sleep Timer was set. See page 33. |
| The clock is wrong | • The power was interrupted and the clock was not reset. See page 30. • There is a problem with the TV. Unplug the set and call for service. |
| The On Timer is blinking | • There is a problem with the TV. Unplug the set and call for service. |
| The color quality is poor | • Tint and Color may be improperly adjusted. See page 28. The Video Status mode may be turned to the wrong setting. See page 34. |
| There are lines across the picture | • There could be interference from another electrical appliance, such as a computer, another TV or VCR. Move any such appliances further away from the TV. |
| The picture is spotted | • There could be interference from a high-wattage appliance, like a hairdryer or vacuum, operating nearby. Move the antenna away from the appliance or change to a coaxial cable connection which is less prone to interference. |
| There are double pictures (ghosts) | • A building or passing airplane can reflect the original signal and produce a second, slightly delayed one. Adjust your antenna position. |
| Picture is snowy (image noise) | • Your antenna may be damaged, disconnected or turned. Check the antenna connection. If the antenna is damaged, replace it. |
| Screen is 80% black | • The Closed Caption Text mode is on. Turn it off in the Closed Caption Menu, page 26. |
| Stereo or bilingual programs can't be heard | • Make sure the MTS settings are correct. See "MTS" on page 29. |
| Static electricity | • It is normal to feel static electricity if you brush or touch the screen. |
| You hear occasional crackling sounds | • It is normal for the TV to make crackling sounds when first turned on or off. Unless the sound or picture become abnormal, this is fine. |
